Manufacturers price servo motor 100ton plastic injection blow moulding machine for sale
The machine is a full automatic injection molding equipment, suitable for processing PP, PS, PE, SAN, PMMA, PC, PETG, PEN and other thermoplastic, widely used in pharmaceutical, health care products, food and beverage, cosmetics, etc..One Mold with Multi-caivity for automatic continuous production technology, using three horizontal station rotary device, hot runner system and multi-stage injection molding system,injection molding, blow molding, demolding three position and action to ensure equipment of high efficiency and energy saving operation, ensure smooth product bottle, the bottleneck of inner and outer diameter and thread high precision, no waste is the standard equipment of modern enterprise environment-friendly production.
Injection Molding Machine samples:
Injection blow molding machine parameters:
| Name | Unit | FG40 |
| Screw diameter | mm | 40 |
| L/D Ratio | 22:1 | |
| Injection Capacity | G | 176 |
| Heating section | 3+N | |
| Total power | KW | 20 |
| System pressure | Mpa | 14 |
| Compressed air pressure | Mpa | 0.7-1.2 |
| Cooling water pressure | Mpa | 0.3-0.4 |
| Product maximum diameter | mm | 120 |
| Product maximum length | mm | 200 |
| Product volume | ml | 3-800 |
| Dimensions | M | 3*1.3*1.7 |
| Equipment weight | Ton | 3.5 |
Mode cavity number control table:
| Product Size | FG40 | |||
| Volume | Neck Dia. | Height | Body Dia. | Cavities |
| 5ML | 10 | 35 | 45 | 9 |
| 10ML | 12 | 40 | 20 | 9 |
| 20ML | 15 | 50 | 25 | 8 |
| 30ML | 20 | 60 | 30 | 7 |
| 40ML | 22 | 65 | 35 | 7 |
| 60ML | 28 | 75 | 40 | 6 |
| 80ML | 30 | 80 | 45 | 5 |
| 100ML | 32 | 85 | 50 | 4 |
| 150ML | 35 | 90 | 53 | 3 |
| 200ML | 38 | 100 | 58 | 3 |
| 400ML | 42 | 120 | 65 | 2 |
| 650ML | 50 | 160 | 80 | 1 |
| 800ML | 40 | 200 | 90 | 1 |
| 100ML | 45 | 200 | 90 | 1 |
