JBW-500B 500J Computer Control Semi-automatic Pendulum Charpy Impact Test Machine

FOB Price

USD $2,400 - $3,600 / Set

1 Set(Min.Order)

Supply Ability 60 Set / Sets per Month
Port Qing Dao
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:	PTE izod charpy impact tester	Place of Origin:	Shandong, China	Model Number:	Charpy Impact Testing Machine
Power:	Electronic

Product Description

JBW-500B 500J Computer Control Semi-automatic Pendulum Charpy Impact Test Machine

Application:

The JBS-500 LCD Display Impact Tester was strictly designed according to national standard GB/T3038 “Inspection for pendulum Impact Testing Machine” and GB/229 “Charpy notch Impact Test Method for metal material”. It is also accordance with international standard ISO148, EN100045 and ASTM E23. It is mainly used to determine the anti-impact capability of metal materials under dynamic load. It is the ideal testing equipment for many metal material manufactories, quality inspection departments and universities. The result will display on both digital display and dial gauge, with PLC control, its reliability is very good, JBS Series can use pendulum’s residual impact energy to achieve the raising again of pendulum, so it’s applicable for batch testing tasks.

Specifications:

Specifications	JBS-500
Impact energy (J)	250, 500
Impact velocity (m/s)	5.4
Raised angle (º)	150
Standard span (mm)	40
Round angle of jaws (mm)	R1-1.5
Round angle of striking edge (mm)	R2-2.5
Size of specimen (mm)	10 x 10 x 55
Power supply	3phs, 380V, 50Hz or 220V,60Hz
Dimensions (mm)	2144 x 736 x 1390
Net Weight (kg)	650
Display	LCD screen

all model:

Specifications	JBS-300	JBS-500	JBS-800
Impact energy (J)	150, 300	250, 500	500, 800
Impact velocity (m/s)	5.2	5.4	5.9
Raised angle (º)	150
Standard span (mm)	40
Round angle of jaws (mm)	R1-1.5
Round angle of striking edge (mm)	R2-2.5
Size of specimen (mm)	10 x 10 x 55
Power supply	3phs, 380V, 50Hz,
Dimensions (mm)	2124 x 600 x 1340	2144 x 736 x 1390		2450 x 1200 x 2455
Net Weight (kG)	450	650		2300
Display	LCD screen
