RH-A01 Automatic Edge-align Fabric Inspecting and Length Measurement Machine
1.This inspecting machine is applied for inspection of various knitted and woven fabric,rolling fabric,measure length and yardage of fabric.
2.Infrared electric eyes are use to supervise the edge alignment device and make the rolled fabric more tidy.
3.Advanced electric length counter can measure the length of fabric precisely.
4.Dual frequency adjustment device, forward and reverse continuously variable transmission,applicable for winding,uncoiling and inspecting fabric.
5.Coiler tension control system makes the degree of tightness of fabric in rolls more flexible.
6.Stainless steel working table,the light box is edge covered by alloy.
7.Stainless steel fabric spreading axis is used to spread the corrugated fabric.
8.Other special requirements can be customizable.
Technical Parameters:
|
1,Working width |
1800mm~2500mm |
|
2,Machine speed |
0~80m/min |
|
3,Motor power |
1.5KW |
|
4,Size |
2730(L)*1280(W)*1950(H)mm |
|
5,Weight |
960KG |
