RH-C01 Table Fabric Inspection Rolling Machine
Purpose:
RH-C01 Fabric Rolling Machine is suitable for the finishing workshops in cotton mill, converting factory and clothing factory to roll up the fabrics in full width, feeding to roll the fabrics in roll or folding way. The finished products after the rolling can be packed for delivery.
Specifications:
Model Number |
RH-C01 |
Max diameter of fabric rolls |
600 mm |
Working width |
1800 mm |
Speed of rolling |
0-60 m/min |
Edge-aligning error for rolling |
≤8 mm |
Maxerror for fabric length-counting |
±0.5% |
Dimensions (L×W×H) |
3050×2000×2200 mm |
Weight |
700kg |
Features:
1 Infinite speed adjustment for rolling
2 Imported photoelectric, special-purpose controller for auto-tracing alignment
3Top-advanced electronic counter in China for fabric length-measurement (can adjust, fix and totalize the length of fabric in meter and yard as well as display the speed of inspecting and rolling)
4 Freely adjustment of fabric tightness by roller speed differ entail device, a pioneering innovation of its kind in China
5 Imported width-expanded set for open and flat fabric pleasing to the eye
