HAS VIDEO Rotary Label Die Cutting Machine With Slitting Function

US$ 7,000 - 11,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Xiaohai
Place of Origin:
Zhejiang, China
Model Number:
FQ-320G
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo port China
Delivery Detail:
Delivery time depends on order quantity.
Brand Name Xiaohai
Place of Origin Zhejiang, China
Model Number FQ-320G
Certification ISO9001
Type Slitting Rewinder
After-sales Service Provided Engineers available to service machinery overseas
Warranty 1 Year
Weight 800kg
Dimension(L*W*H) 1800*1000*1600mm
Condition New
Voltage 220V
Computerized No



Rotary die cutting-slitting machine with turret rewinder



Characteristics:

1. Unwind shaft with limiting baffle, easy for material fixing. Unwind web guide adopt frame mode, easy for adjusting, and with high precision.

2. Die cutting axle head fixing seat adopt circle design, it is easy for assemble and disassemble, compare with traditional square shape fixing seat, it saves half time. Die cutting pressure adjusting screw arbor is rotation structure, it do not need to take off.

3. Up rewind adopt turret structure to improve work efficiency.

4. Transmission adopt synchronous belt to reduce noise.

5. Unwind, rewind and waste collection all adopt magnetic powder brake/clutch to control, operation stable.

6. Unwind adopt auto tension control for constant tension, rewind adopt taper tension control

7. Unwind, rewind, waste collection air shaft all auto air charge.

8. This machine with function of auto length counting, number counting, length setting, auto stop, ultrasonic sensor web guiding etc.

Main technical parameters:



Slitting speed

120m/min

Die cutting speed

120m/min

Die cutting girth

240-450mm

Max.width of roll

320mm

Max.diameter of unwinding roll

650mm

Max.diameter of Rewinding roll

Up: 200mm(turret)

Down: 650mm

Overall size

1800*1000*1600mm

Weight

800KG

Power supply

AC220V

HAS VIDEO Rotary label die cutting machine with slitting functionHAS VIDEO Rotary label die cutting machine with slitting functionHAS VIDEO Rotary label die cutting machine with slitting functionHAS VIDEO Rotary label die cutting machine with slitting functionHAS VIDEO Rotary label die cutting machine with slitting function

HAS VIDEO Rotary label die cutting machine with slitting functionHAS VIDEO Rotary label die cutting machine with slitting functionHAS VIDEO Rotary label die cutting machine with slitting function
