Specimen Grinding Machine

Specimen Grinding Machine

Used to grind and polish concrete specimens, natural stones, ceramic materials, rock samples etc.The cube cylinder and core specemens can be easily locked on the table and the grinding head can be radially moved either manually or automatically in both directions so the only manual operation requested is the lowering of the grinding head by the top hand wheel. The machine is supplied complete with chip guard, coolant tank, motor pump, one set of abrasive sectors and instruction manual.

Specifications:

Automatic grinding input: 0.04- 0.12mm

Grinding spec. Specimens: 50-150mm cubes dia. 50-dia.120mm cylinders

Degree of finish (by standards of rough machining): Ra 3.2

The precision of standard flatness ±0.05mm (within 50 range)

Diameter of the grinding wheel: 200mm

Cooling devices: receive water cooling
