Precise 7L air content meter for fresh mix concrete
The Meter is the industry’s most popular kit for testing entrained air.Whether going into the ready mix truck or coming down the chute, it gives fast results. Always accurate. The kit contains everything needed to perform the test and-very importantly -to keep the unit in claibration.
The air meter unit consists of 2 main parts: the base (measuring chamber) and the cover assembly. The cast aluminum base has machine-fl anged rims. The interior surfaces of the base and surfaces of rims, fl anges and other component parts are machined to facilitate frequent water clean-up. The unit is designed for easy disassembly in order to replace worn or damaged parts in the field.
| Code | LA-0316 | B-2030 |
| Capacity (L) | 7 | 1 |
| Air content range | 0-10% | 0-50% |
| Accuracy |
±0.1%(1%-6% of air content) ±0.2% (6%-10% of air content) |
±0.1% |
| Dimension (mm) | dia.330x500 | dia.200x320 |
| Weight (kg) | 10 | 4 |
Parts and Accessories
Roller Meter - Syringe, 3 oz
Tamping Rod, 12 in (30.5 cm) with 5/8 in (15.9 mm) rounded tip
1 Pressure Chamber
2 Pressure Chamber Cap
3 Chamber Elbow
4 Chamber Gasket, two required (top & bottom)
5 Air Bleeder Valve Assembly
6 Air Bleeder Valve Cap
7 Gauge for Press-Aire Meter
8 Air Bleeder Valve Stem
9 Air Bleeder Gasket
10 Needle Valve Stem
11 Needle Valve Stem
12 Needle Valve Nut
13 Needle Valve Lever
14 Needle Valve Spacer
15 Needle Valve O-Ring
16 Needle Valve Spring
18 Needle Valve Seat
19 Lid
21 Lid Petcock, Instruction label
29 Aluminum Unit Weight Bucket - Base- .25 cu ft (7.1L)
36 Needle Valve Stem O-ring, Gauge Glass, Latch Stud
44 Latch Clamp Tab
45 Latch Assembly for Lid
46 Pan Hd Screw, HD #10 x 1/2 in
61 5/16 in WB Nut
62 5/15 in x 1/8 in Adapter
63 O-ring, Needle Valve, O-ring, Super Pump Seal,O-ring, Super Pump Piston Seal, Super Pump Check Valve
20 O-ring Lid Seal
