China soil manual dynamic cone penetrometer DCP for sale
The Dynamic Cone Penetrometer is a long steel rod with a standard size hardened steel cone at the penetrating end. Its length is approximately two metres, but it can be extended by extension rods. At upper end of the steel bar is a captive weight surrounding the rod, this weight is able to fall freely through a given drop height to achieve a standard amount of penetrative effort at every drop. By measuring the penetration of the cone against number of drops of the weight it is possible to plot resistance to penetration and indirectly the strength / compaction of the layer being tested. This equipment is very useful for testing fill compaction, especially in trench reinstatement, performed with care. It is possible to obtain an approximate CBR figure from the results of using this equipment by applying a simple formula. It is a guide figure but still useful to know.
Penetrometers are used to establish the thickness of different stratifications when investigating the suitability of a site for bridge, road and other construction works. In general if the ground is not too compact, penetration tests with the lightweight penetrometer can be carried out to depths of about 6 m.
16-T0012/A Schematic operating principle
Accessories
8 kg weight dropping mass trough a height of 575 mm
Anvil with driving rod
Penetration rod with 60°, 20 mm dia. cone
Spanners, Tommy bar, bottle of adhesive
All contained in a carrying case,case dimensions:1200*350*200mm approx
We supply a wide range of product to meet your various needs.
Experienced sales team help you with equipment selection.
Special equipment specification can be customized according to your requirements.
Enthusiastic after sale service.
Packaging:Standard exporting carton meet the long transportation requirement.
Shipping:by air,sea,express are all available,we'll help you with transportation selection according to goods quantity.
