Electric three-speed soil direct shear test equipment with digital rate controller
To determine the shearing strength of the soil using the Electric three-speed soil direct shear test equipment.In many engineering problems such as design of foundation, retaining walls, slab bridges, pipes, sheet piling, the value of the angle of internal friction and cohesion of the soil involved are required for the design. Direct shear test is used to predict these parameters quickly. The laboratory report cover the laboratory procedures for determining these values for cohesionless soils.
Strain controlled Electric three-speed soil direct shear test equipment consists of shear box, soil container, loading unit, proving ring, dial gauge to measure shear deformation and volume changes. A two piece square shear box is one type of soil container used.
A proving ring is used to indicate the shear load taken by the soil initiated in the shearing plane.
Specification
| Vertical laod | 50kpa,100kpa,200kpa,300kpa,400kpa |
| Lever ratio | 1:12 |
| Level shear force | Max.1.2KN |
| Sample are (cm²) | 30 |
| Shear rate(mm/min) | 0.02,0.8,2.4 |
| Power source | 220V±10%,50Hz |
| Dimmension(mm) | 850*550*1100(L*W*H) |
| Weight | 60kg |
We supply a wide range of product to meet your various needs.
Experienced sales team help you with equipment selection.
Special equipment specification can be customized according to your requirements.
Enthusiastic after sale service.
Packaging:Standard exporting carton meet the long transportation requirement.
Shipping:by air,sea,express are all available,we'll help you with transportation selection according to goods quantity.
