NDT Apparatus Digital FSY Ultrasonic Concrete Crack Depth Gauge for Sale

NDT Apparatus Digital FSY Ultrasonic Concrete Crack Depth Gauge for Sale photo-1
US$ 600 - 800 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Tianpeng
Place of Origin:
Hebei, China
Model Number:
FSY
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port in China
Delivery Detail:
Delivery time depends on order quantity.
Brand Name Tianpeng
Place of Origin Hebei, China
Model Number FSY
Power Electronic

DESCRIPTION:

Concrete crack depth tester

The crack depth tester measures the crack depth of the concrete surface based on the principle of sound wave diffraction.



Features
1. New upgraded wireless cloud transfer function;
2. It adopts three anti-shell design, waterproof, dustproof and shockproof;
3. The field test is simple and fast, and does not require manual interpretation of the acoustic parameters, directly showing the crack depth;
4. The instrument is easy to operate, quick to master, and requires no professional knowledge;
5. The test accuracy is high, the maximum error is not more than 5mm or 2%-10% of the actual seam depth;
6. The test using the bracket does not require scribing, the spacing is accurate and adjustable, and the test efficiency is greatly improved.



Technical Parameters



Specifications of the tester Waterproof index: IP65
Screen size: 5-inch
Resolution: 160x128
Dimension: 195x140x45mm
Net weight: 0.8kg
Depth measuring range ≤500mm
Error ≤5mm or 2%~10% of the actual depth
Measuring mode Standard Measurement     Quick Measurement (quick test support)
Data transmission interface USB
Data Storage capacity 20000 groups
Data transmission mode Wireless cloud transmission (optional)
Power Large capacity Lithium battery
Working environment Temperature: -10ºC~40ºC
Humidity: less than 90% RH
Packing specifications Material: plastic
Dimension: 420x140x335mm
Gross weight: 5.5kg
