Home > Electrical & Electronics > Power Supply & Distribution > Switching Power Supply > TOPPOWER 30W 3KV Isolation Wide Input AC/DC Converters

TOPPOWER 30W 3KV Isolation Wide Input AC/DC Converters

Name: TOPPOWER 30W 3KV Isolation Wide Input AC/DC Converters
Brand: TOPPOWER
SKU: 166412867
Availability: InStock

TOPPOWER 30W 3KV Isolation Wide Input AC/DC Converters thumbnail-1

TOPPOWER 30W 3KV Isolation Wide Input AC/DC Converters thumbnail-2

TOPPOWER 30W 3KV Isolation Wide Input AC/DC Converters thumbnail-3

TOPPOWER 30W 3KV Isolation Wide Input AC/DC Converters photo-1

TOPPOWER 30W 3KV Isolation Wide Input AC/DC Converters photo-2

TOPPOWER 30W 3KV Isolation Wide Input AC/DC Converters photo-3

US$ 0.21 ≥7777777777666 Pieces

Key Specifications

Get Latest Price

Brand Name:

TOPPOWER

Place of Origin:

China

Model Number:

TP25AU ,TP30AU ,

Contact Supplier Request Quote Chat Now

Guangzhou Top Power Electronics Techonology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

gunagzhou

Delivery Detail:

10 days

Product Details
Company Profile
Contact Us

Brand Name TOPPOWER

Place of Origin China

Model Number TP25AU ,TP30AU ,

Output Power 1 - 50W

Output Type Single

Output Current ma

Output Frequency hz

Output Voltage vdc

Input Voltage 220V

The rated output power of TP25AU~TP30AU converters is 25~30W with wide input voltage range, for both AC input and DC input application. High reliability, precision, large power density, ultra-small size, no external heat sink required, stable output voltage and etc, with over current protection, EMI filter circuit, the rectifier filter circuit, 3000V isolation voltage, short circuit, overload, internal thermal protection, Widely used in telecommunications, industrial control, instrument, data acquisition, signal control and other electronic systems.

Universal input voltage range Both for AC and DC input voltage Wide input voltage:2:1 and 4:1

Fixed switching frequency Overheat protection Over current protection

Short circuit protection RoHS compliant Operating temperature: -40℃to 70℃

25~30W 3KVAC Isolation Wide Input AC/DC Converters Board Mount Encapsulated power supply

Part Number	Input Voltage			Output
	Rated		Range values	Voltage（VDC)	Current （A）
	（VAC)			Voltage（VDC)	Current （A）
TP25AU220S03W	220(4:1)	85-265		3.3	5.0
TP25AU220S05W	220(4:1)	85-265		5	5.0
TP25AU220S12W	220(4:1)	85-265		12	2.08
TP25AU220S15W	220(4:1)	85-265		15	1.67
TP25AU220S24W	220(4:1)	85-265		24	1.04
TP25AU220S48W	220(4:1)	85-265		48	0.5
TP25AU220D05W	220(4:1)	85-265		±5	±2.5
TP25AU220D12W	220(4:1)	85-265		±12	±1.04
TP25AU220D15W	220(4:1)	85-265		±15	±0.83
TP25AU220D05P03W	220(4:1)	85-265		+5/+3.3	4.9/0.1
TP25AU220D05P05W	220(4:1)	85-265		+5/+5	4.9/0.1
TP25AU220D05P12W	220(4:1)	85-265		+5/+12	4.8/0.1
TP25AU220D05P15W	220(4:1)	85-265		+5/+15	4.7/0.1
TP25AU220D05P24W	220(4:1)	85-265		+5/+24	4.5/0.1
TP25U220T05D05W	220(4:1)	85-265		+5/±5	4.8/±0.1
TP25AU220T05D12W	220(4:1)	85-265		+5/±12	4.5/±0.1
TP25AU220T05D15W	220(4:1)	85-265		+5/±15	4.4/±0.1
TP30AU220S05W	220(4:1)	85-265		5	6.0
TP30AU220S12W	220(4:1)	85-265		12	2.5
TP30AU220S15W	220(4:1)	85-265		15	2
TP30AU220S24W	220(4:1)	85-265		24	1.25
TP30AU220D05W	220(4:1)	85-265		±5	±3
TP30AU220D12W	220(4:1)	85-265		±12	±1.25
TP30AU220D15W	220(4:1)	85-265		±15	±1
TP30AU220D05P05	220(2:1)	165-265		+5/+5	5.2/0.8
TP30AU220D05P12	220(2:1)	165-265		+5/+12	4.0/0.8
TP30AU220D05P15	220(2:1)	165-265		+5/+15	3.6/0.8
TP30AU220D05P24	220(2:1)	165-265		+5/+24	3.6/0.8
TP30AU220D05P05W	220(4:1)	85-265		+5/+5	5.2/0.8
TP30AU220D05P12W	220(4:1)	85-265		+5/+12	4.0/0.8
TP30AU220D05P15W	220(4:1)	85-265		+5/+15	3.6/0.8
TP30AU220D05P24W	220(4:1)	85-265		+5/+24	3.6/0.8
TP30AU220T05D12W	220(4:1)	85-265		+5/±12	4.4/±0.34
TP30AU220T05D15W	220(4:1)	85-265		+5/±15	4.4/±0.27
TP30AU220T05D24W	220(4:1)	85-265		+5/±24	4.4/±0.17
