MS H ProT Lab Magnetic Hot Plate Stirrer 340C
US$ 90 - 1,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Drawell
Place of Origin:
Chongqing, China
Model Number:
MS-H-ProT
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing/Shanghai/Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
MS H S Magnetic Hot Plate Stirrer With 5inchUS$ 180 - 550MOQ: 1 Piece -
Laboratory Chemical LCD Hot Plate With Magnetic StirrerUS$ 320 - 357MOQ: 1 Piece
-
Heat Function Laboratory Hot Plate Magnetic StirrerUS$ 185 - 210MOQ: 1 Piece
-
MS6 Pro Laboratory Hot Plate Magnetic Stirrer Without HeatingUS$ 90 - 1,500MOQ: 1 Set
-
Coated Laboratory Magnetic Stirrer Without HeatingUS$ 143 - 162MOQ: 1 Piece
Brand Name
Drawell
Place of Origin
Chongqing, China
Model Number
MS-H-ProT
Product Description
LCD Digital Magnetic Hotplate Stirrer with Time
Features:
Safe Heating and Mixing
• Conforms to international safety standards and regulations
• Brushless DC motor is maintenance free and explosion-proof
• Fully closed aluminum alloy casing has a high IP protection class(IP42)
• The temperature sensor consists of two independent safety circuits, which switches off heating in case of any over temperature situation
• "HOT" sign warning to prevent burns, even if switched off.
Precise temperature and speed control
• Temperature is up to 340°C
• Intergrated temperature sensor PT 1000 for precise temperature control.
Control accuracy is ±0.2°C
• Excellent heat control accuracy at the work plate: ±1(<100°C) ±1%(>100°C)
• Electronic speed control, max speed is 1500rpm.
Convenient
• Digital process timer allows for unattended operation and can be set from 1min to 99h 59min. When the set time has elapsed, the operation stops
• Backlit LCD display target and actual temperatures and speed
• Automatically identifies temperature sensor PT1000 and transfer to PT1000 operation mode.
• Stainless steel with ceramic coated hotplate allows immediate heat transfer for quick heat-up times, chemical-resistant and scratch proof
• Max. stirring quantity 20L
• PC can control and document all parameters via RS232 interface
• Used with a wide variety of accessories
Product Paramenters
Work plate dimension |
φ135mm(5 inch) |
Work plate material |
stainless steel cover with ceramic |
Motor type |
Brushless DC motor |
Motor rating input |
18W |
Motor rating output |
10W |
Power |
550W |
Heating output |
500W |
Voltage |
100-120/200-240V 50/60Hz |
Stirring positions |
1 |
Max. stirring quantity[H2O] |
20L |
Max. magnetic bar[length] |
80mm |
Speed range |
100-1500rpm resolution±1rpm |
Speed display |
LCD |
Temperature display |
LCD |
Heating temperature range |
Room temp.-340°C, increment 1°C |
Temperature control accuracy |
±1°C(<100°C) ±1%(>100°C) |
Over temperature protection |
360°C |
Temperature display accuracy |
±0.1°C |
External temperature sensor |
PT1000 (accuracy ±0.2) |
"Hot" warning |
50°C |
Timer function |
1min to 99h 59min |
Data connector |
RS232 |
Protection class |
IP42 |
Dimension[WxDxH] |
160×280×85mm |
Weight |
2.8kg |
Permissible ambient temperature and humidity |
5-40°C, 80%RH |
