Heat Function Laboratory Hot Plate Magnetic Stirrer
US$ 185 - 210
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Drawell
Place of Origin:
Chongqing, China
Model Number:
MS-H-S
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
MS6 Pro Laboratory Hot Plate Magnetic Stirrer Without HeatingUS$ 90 - 1,500MOQ: 1 Set -
Coated Laboratory Magnetic Stirrer Without HeatingUS$ 143 - 162MOQ: 1 Piece
-
MS7 H550 Pro Magnetic Stirrer HotplateUS$ 398 - 451MOQ: 1 Piece
-
Orbital And Linear Shaker Reciprocate Shaker Laboratory Cheap ShakerUS$ 368 - 368MOQ: 1 Piece
-
Shaker Electric Shaker For Laboratory Orbital And Linear ShakerUS$ 690 - 690MOQ: 1 Piece
Brand Name
Drawell
Place of Origin
Chongqing, China
Model Number
MS-H-S
Product Description
Classic Magnetic Hotplate Stirrer
Model：MS-H-S
Features:
- Stainless steel with ceramic coated hotplate resists to corrosion
- Separated safety circuit, automatically stop heating when temperature over 350℃
- Motor with electronic speed control, constant speed even during changes in load
- Variable speed of motor
- High magnetic adhesion, prevent the stirrer bar escape
- Enclosed assembly with protection class IP42 and DC brushless motor guarantees long service
- Stainless steel with ceramic coated hotplate
Product Paramenters
Work plate dimension |
φ135mm(5 inch) |
Work plate material |
stainless steel cover with ceramic |
Motor type |
Brushless DC motor |
Motor rating input |
18W |
Motor rating output |
10W |
Power |
550W |
Heating output |
500W |
Voltage |
100-120/200-240V 50/60Hz |
Stirring positions |
1 |
Max. stirring quantity[H2O] |
20L |
Max. magnetic bar[length] |
80mm |
Speed range |
100-1500rpm resolution±1rpm |
Speed display |
Scale |
Temperature display |
Scale |
Heating temperature range |
Room temp.-340°C |
Over temperature protection |
350°C |
Temperature display accuracy |
±0.5°C |
Protection class |
IP42 |
Dimension[WxDxH] |
160×280×85mm |
Weight |
2.8kg |
Permissible ambient temperature and humidity |
5-40°C, 80%RH |
Data connector |
RS232 |
Protection class |
IP42 |
Dimension[WxDxH] |
160×280×85mm |
Weight |
2.8kg |
Permissible ambient temperature and humidity |
5-40°C, 80%RH |
Product Images
