US$ 11,255 - 11,450
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Drawell
Place of Origin:
Shanghai, China
Model Number:
Gentier 48E
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing/Shanghai/Shenzhen/Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
96 Well Real Time PCR Machine PriceUS$ 10,000 - 18,800MOQ: 1 Piece -
Pcr Thermal Cycler Pcr Machine PriceUS$ 1,800 - 2,500MOQ: 1 Piece
-
Gentier 48E Precision DNA Amplification QPCR Real Time Quantitative PCRUS$ 11,250 - 11,800MOQ: 1 Piece
-
High Quality Real Time PCR Machine With Six Channels With Gradients Gentier 96EUS$ 18,500 - 22,500MOQ: 1 Piece
-
4 Channel Gradient Real Time Pcr Machine PriceUS$ 12,000 - 21,000MOQ: 1 Piece
Brand Name
Drawell
Place of Origin
Shanghai, China
Model Number
Gentier 48E
|
Real-Time Quantitative PCR |
|||
| Gentier 48E | |||
| Thermal Block | |||
| Sample capacity(wells) | 48 | ||
| Reaction Volume | 5-100 μL | ||
| Consumables | 0.2ml 8-strip tubes ,0.2ml PCR single tube(Optical flat cap,clear tube) | ||
| Temperature range | 0°C-100°C | ||
| Heating/cooling method | Peltier | ||
| Max heating rate | 8.0°C/sec | ||
| Average heating rate | 6.2°C/sec | ||
| Max cooling rate | 6.2°C/sec | ||
| Average cooling rate | 4.5°C/sec | ||
| Temperature accuracy | ±0.1℃ | ||
| Temperature uniformity | ±0.2℃ | ||
| Gradient Range | 1°C-40°C | 1°C-40°C | |
| Gradient block | 8 row | 8 row | |
| Special temperature portocol | Gradient PCR,Long PCR,Touch Down PCR | Gradient PCR,Long PCR,Touch Down PCR | |
| Heat Lid | |||
| Temperature range | Room Temperature–110°C | ||
| Optical System | |||
| Excitation Source | 4LEDs | 2LEDs | |
| Detector | Photodiode | ||
| Detection Position | Excitation and scan from lateral | ||
| Detection method | 4 channels scanning at the same time, no edge effect. | ||
| Detection time | 2 seconds for 48 wells for all channels | ||
| Range of excitation/ emission wavelengths (nm) |
1 465 /510 (FAM,SYBR Green I,SYTO9,EvaGreen,LC Green) 2 527/ 563 (HEX,VIC,TET,JOE) 3 580 /616 (ROX,Texas Red) 4 632/ 664( Cy5) |
1 465 /510 (FAM,SYBR Green I,SYTO9,EvaGreen,LC Green) 2 527/ 563 (HEX,VIC,TET,JOE) |
|
| Probe | Taqman Probe,Molecular beacons probe,Scorpion probe | ||
| Multiplexing | Up to 4 targets | Up to 2 targets | |
| Fluorescence Linearity | r≥0.990 | ||
| Fluorescence Dynamic Range | Adjustable | ||
| Performance | |||
| Sample Linearity | /r/≥0.999 | ||
| Sample repeatability | Ct value CV≤0.5% | ||
| Sample Dynamic Range | 1-1010 copies | ||
| Software Funtions | |||
| Data Analysis modes | Qualitative analysis,Absolute quantification, Relative quantification,Genotyping analysis,Endpoint analysis, Melt curve analysis, High Resolution Melting |
||
| Control modes | 1.7 touch screen 2. PC direct control 3. WLAN control(One PC can control max 10 units, and device can be controled by any PC in the WLAN) |
||
| Data Stroage | Upload and download through USB disk,1000 results can be stored in machine | ||
| Power failure protection | Automaticly start running experiments after power supply, no need wait PC software | ||
| Customize Report | Templetes reserved ,report can customized | ||
| Administration Management | Administrator can set funtions limts for users | ||
| Fault Management | Fault report and analysis, solution instruction | ||
| LIS connection | CSV,Excel,TXT format data output,open port for LIS connection | ||
| Others | |||
| PC operating system | Win 7, Win 10 | ||
| Communication Port | 1 ethernet and 2 USB | ||
| Footprint(WxDxH) | 260mm X 400mm X 2605mm | ||
| Weight | 11kg | ||
| Power usage | AC 100 to 125 V / 200 to 240 V (50/60 Hz). | ||
| power consumption | 600VA | ||
| Work environment |
Tempereture:10°C~30°C Humidity:20%~85% |
||
