BDS400 Inverted Biological
New research and new development
Apply to observation and cultivation for cell tissue
Wide field eyepiece, view field up to Φ23mm,more comfortable for observation
Long working distance condenser N.A. 0.30,Working distance:72mm
Working distance: 195mm (without condenser),available for extra high culture dish
Large size stage, convenient for research. Size:240mm(X)× 210(Y)mm
Mechanical stage available for 96 holes plate. Moving range:128mm(X)× 80(Y)mm
Large diameter quintuple nosepiece can be installed more objectives, more convenient for using.
Light distribution (both): 100 : 0 (100% for eyepiece);
80 : 20 (80% for trinocular head and 20% for eyepiece)
BDS400 Inverted Biological Microscope Outfits:
Item | Specification | Outfits | |
Eyepiece | WF10×/22mm(23mm is optional) | 1 | |
LWD Infinity Plan Objectives | LPL 4×/0.11 | W.D.=12.1mm | 2 |
LPLAN 10×/0.25 | W.D.=8.3mm | 1 | |
LPLAN 20×/0.40 | W.D.=7.2mm | 1 | |
LPLAN 40×/0.60 | W.D.=3.4mm | 1 | |
LWD Infinity Plan Phase Contrast Objectives | LPL Ph P 10×/0.25 | W.D.=8.3mm | 2 |
LPL Ph P 20×/0.40 | W.D.=7.2mm | 1 | |
LPL Ph P 40×/0.60 | W.D.=3.4mm | 2 | |
Annular Spot | 10× | 2 | |
20×/ 40× ( for both 20× and 40× ) | 1 | ||
Seidentopf Trinocular Head | Inclined 45°, interpupilary distance: 48-76mm Light distribution (both): 100: 0(100% for eyepiece) 80:20 (80% for trinocular head, and 20% for eyepiece) | 1 | |
Nosepiece | Quintuple | 1 | |
Mechanical Stage | Stage size: X×Y: 210×241mm, Round slide size:Φ110mm, Attached mechanical stage (available for 96 holes plate, moving range X×Y:128×80mm.) | 1 | |
Culture Dish Holder | 65mm | 2 | |
54mm | 1 | ||
35mm | 2 | ||
Condenser | Long working distance, Quickly detachable , N.A.0.3, Working distance: 72mm (with condenser),195mm(without condenser). | 1 | |
Koehler Illumination | 6V/30W (input voltage:100V~240V) | 1 | |
Filter | Blue | 1 | |
Green | 1 | ||
Amber | 2 | ||
Grey | 2 | ||
C-mount | 1× C-Mount (better for digital photograph) | 2 | |
0.5× C-Mount ( focus adjustable, better for digital camera) | 2 | ||
Adaptor for Digital Photograph | Use for CANON/NIKON/OLYMPUS etc. | 2 | |
Epi Fluorescence Illumination | Epi fluorescence unit , field diaphragm,center adjustable. | 2 | |
100W mercury lamp (OSRAM) | 2 | ||
B, G, V, UV fluorescence filters can be chosen. | 2 | ||
Digital mercury lamp power box (input voltage:100V~240V) | 2 | ||
Note: "1"In Table Is Standard outfits, "2" Is Optional Accessories.
Packing Size: 660mm×590mm×325mm Gross Weight: 18 kgs Net Weight: 13.5 kgs
Note: In Table Is Standard outfits, Is Optional Accessories.
Packing Size: 660mm×590mm×325mm Gross Weight: 18 kgs Net Weight: 13.5 kgs
