LC-MS 1000 Liquid Chromatography Mass Spectrometer

LC-MS 1000 Liquid Chromatograph Mass Spectrometer

LC-MS 1000 liquid chromatograph mass spectrometer is a high-end instrument in the organic analysis market from Drawell. Liquid chromatography (LC) is capable of effectively separating organic components from organic compounds from the sample, and mass spectrometry (MS) is capable of analyzing organic matter one by one. The powerful electric spray ionization technique makes the LC-MS mass spectrum chart simple, and the data processing is simple too. LC-MS is an essential tool for the analysis of organic compounds, such as pharmaceutical, food inspection, production process control, quality inspection and other departments.

Features

1. The position of the ion source can be adjusted flexibly, and the adaptability of complex sample analysis under different flow rate is enhanced

2. Multi channel acquisition function, rapid increase the analysis speed and work efficiency

3. The scanning speed (up to 10000 amu/s model, a wide range of histogram), scanning (10 - 1100amu)

4. Provide positive and negative ion mode switching, high detection sensitivity (10pg, S/N = 50:1),

5. High level of software integration (LC high pressure pump, automatic sampler, constant temperature box, ultraviolet detector and mass spectrometry and data processing integrated in one software)

6. Powerful automatic calibration function

Technical parameter

Mass range: m/z 10-1500 amu

Resolution: unit mass resolution 1amu (≤0.7amu)

Mass accuracy: ≤±0.20 amu (in the range of the calibration quality of scanning mode)

Mass shaft stability: ≤±0.2 amu/12h (constant temperature:±2℃)

Scan rate: standard mode 1000amu/s, fast scan mode 10000amu/s

SNR: ESI+, 10pg, S/N = 50:1(RMS)

Peak area repeatability: RSD ≤ 4.6%

Retention time repeatability: RSD ≤1.5%
