Raman Microscope Manufacturer for Lab
- Shanghai
- T/T Credit Card
You May Like
Product Details
Brand Name | Drawell | Place of Origin | Shanghai, China | |
Model Number | DTR8300BS |
Product Description
Raman Microscope DTR8300BS
l Feature:
l True focus, guaranteed more accurate Raman image
l Ultra-high spatial resolution
l Unique software control switching path
l Super high stability
l Quickly locate and quickly locate the focus position
l High quality objective lens, spot micron scale
l 5 million cameras, accurate image
l Laser wavelength can be selected from 532, 785 and 1064 nm
l Equipped with a high performance spectrometer
l The usb 2.0/LAN interface is directly connected to the computer
l Application:
l Biological sciences
l Forensic analysis
l Material science
l Medical immunoassay
l Agricultural and food safety
l Water pollution analysis
l Gemstone
l Environmental science
l Feature:
l True focus, guaranteed more accurate Raman image
l Ultra-high spatial resolution
l Unique software control switching path
l Super high stability
l Quickly locate and quickly locate the focus position
l High quality objective lens, spot micron scale
l 5 million cameras, accurate image
l Laser wavelength can be selected from 532, 785 and 1064 nm
l Equipped with a high performance spectrometer
l The usb 2.0/LAN interface is directly connected to the computer
l Application:
l Biological sciences
l Forensic analysis
l Material science
l Medical immunoassay
l Agricultural and food safety
l Water pollution analysis
l Gemstone
l Environmental science
DTR8300 Automated focusing Raman Microscope | |
Spectral resolution | 5 cm-1 |
Spectral range | 200-3800,150-2600 cm(Other wave ranges can be customized to a minimum of 50cm-1) |
Spectral stability | σ/μ < 0.5% (COT 8 hours) |
Temperature stability | Spectral shift≤1 cm-1(10-40 ℃) |
SNR | 2000:1 |
Detector | TEC refrigeration 2048*64 pixels CCD |
Wavelength range | 200nm-1100nm |
Pixel size | 14μm*200μm |
Detector dynamic range | 10000:1 |
Laser central wavelength | 785nm (+/-0.5nm) |
5 megapixel industrial camera | 3 megapixel or 5 megapixel industrial camera |
Focus mode | Conjugate focus |
laser power | >550mW(software adjustable) |
Laser beam diameter | >1μm |
Laser stability | σ/μ <±0.2% |
Laser bandwidth | 0.08 nm |
Communication mode | USB2.0 |
