532nm DPSS Green 10W Laser Module

FOB Price

USD $7,600 - $15,200 / Unit

1 Unit(Min.Order)

Supply Ability 5000 Piece / Pieces per Month
Port Changchun
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:

CNI

Place of Origin:

Jilin, China

Model Number:

MGL-W-532

Product Description

Product Application

All solid state 532nm green laser is made features of ultra compact, long lifetime and easy operation, which is widely used in collimation, laser medical treatment, scientific experiment, optical instrument, laser display, laser lighting show, etc.

Specifications for 10W 20W 532nm DPSS Green Laser Module
Model	MGL-W-532A	MGL-W-532B
Wavelength (nm)	532±1
Output power (mW)	>5000, 5500, 6000, …, 10000	>5000, 5500, 6000, …, 20000
Transverse mode	TEM00	Near TEM00
Operating mode	CW
Power stability (rms, over 4 hours)	<1%, <3%, <5%, <10%
Warm-up time (minutes)	<10
M2 factor	<1.5	3.0~6.0 (<3.0 on request)
Beam divergence, full angle (mrad)	<0.7	<2. 0
Beam diameter at the aperture (mm)	~4. 0
Beam height from base plate (mm)	93.5
Polarization ratio	>50:1
Operating temperature (℃)	10~35
Power supply (90-264VAC)	PSU-W-LED/PSU-W-FDA
Modulation option	TTL on/off, 1Hz-1KHz, 1KHz-10KHz, 10KHz-30KHz; and Analog modulation option
Expected lifetime (hours)	10000
Warranty period	1 year

Dimensions

Laser Head

Power Supply

PSU-W-LED power

Certifications

Packing & Delivery

Company Information

Changchun New Industries (CNI) founded in 1996, located in Changchun, CHINA, is a leading manufacturer of solid-state and diode laser systems. Our products include green laser, blue laser, yellow laser, red laser, RGB laser, infrared laser, UV laser, single longitudinal mode laser and Q-switched laser systems. CNI lasers are featured with high performance, low cost and excellent laser beam quality, which are specifically designed for OEM, scientific, industrial and instrumentation use. In addition, CNI lasers are ISO-9001, FDA, CE and JQA certified.

CNI also provides laser components and accessories, we aim to offer customers complete laser solutions for all solid state lasers, diode lasers, laser marking system with our most convenient and rapid service.

Customer Visit

Exhibitions

FAQ

1. What about the delivery?

TNT UPS FEDEX DHL

2. What about the warranty?

For 1 year

3.How to pay?

T/T Western Union

4. How to visit our factory?

You can contact us by following ways to apply for visiting our factory:

（1） International Tel: +86-431-85603799

（2） Fax: +86-431-87020258

5. How to find nore product of our company?

Search our web to find more products(including more contact way )
