Home > Products > brushless dc motors > 110BLS04 48V 3 Phase Bldc Motor , Rated 48 Volt 6.5Nm, 2500rpm, Peak 20Nm
110BLS04 48V 3 Phase Bldc Motor , Rated 48 Volt 6.5Nm, 2500rpm, Peak 20Nm
US$ 65 - 150
/ Piece
2 Pieces(Min. Order)
- shanghai
- T/T Credit Card
You May Like
-
86RBL Round 86mm 48 Volt Dc Motor Brushless Option 24v 36v, Big Torque High Power Upto 750w
-
42mm High Torque Brushless dc Planetary Gear Motor With Electric Brake
-
86RBL01 BLDC Motor Kit, Rated 48v 3000rpm 1Nm 300w
-
Sensorless BLDC Motor, 57mm Brushless dc Motor IP54 24VDC 6000 Rpm
-
Dia. 28mm BRUSHLESS DC PLANETARY GEAR MOTOR CATALOGUE
-
56JXE300k.57BL Brushless dc Planetary Gearbox Motor , Rated Torque Upto 30Nm
Product Details
| Brand Name | smartautomation | Place of Origin | Jiangsu, China | |
| Model Number | 110BLS04 | Type | Servo Motor | |
| Certification | CE, ROHS | Torque | 6.5Nm | |
| Usage | Boat, Car, Electric Bicycle, Fan, Home Appliance, Other | Construction | Shunt Wound | |
| Efficiency | IE 1 | Protect Feature | Drip-proof | |
| Continuous Current(A) | 12A | Speed(RPM) | 2500rpm | |
| Commutation | Brushless |
Product Description
|
main applications of bldc motor |
|
|
|
|
|
|
|
|
|
Industry |
Content |
Industry |
Content |
|
Medical equipment |
Hand-held surgical instruments |
Aerospace Industry |
Electric seat adjustment post |
|
|
|
||
|
Surgical robot |
Flight recorders |
||
|
|
|
||
|
Micro-injection pump; Peristaltic pump |
Autopilot |
||
|
|
|
||
|
Dialyzer |
Air-conditioning system |
||
|
|
|
||
|
Automatic dosing system |
Space Robot |
||
|
|
|
||
|
Radiation therapy equipment |
|
||
|
|
|
||
|
Diagnostic equipment and testing instruments |
|
||
|
Robot |
Humanoid robot |
Auto industry |
Adjustable shock absorbers |
|
|
|
||
|
Service robots |
Emission abatement system |
||
|
|
|
||
|
Teaching Robots |
Electronic steering |
||
|
|
|
||
|
|
Electronic tachometer
|
||
|
Industrial Automation |
Precision Positioning System |
Communications Equipment |
Antenna System |
|
|
|
||
|
Handling System |
Copier / printer / plotter |
||
|
|
|
||
