ductile iron pipe
Ductile iron pipes are widely used for drinking water supply/transmission both government and privates sectors.The product detailed informations are as following:
a.Ductile iron pipes standard: ISO2531-1998,BSEN545-2006
b.Effective length: 6M for 40' container, 5.7M for 20' container.
c.Pipe ends: Spigot and socket ends, with 100% SBR gaskets.
d.Internal coating: cement mortar lining comply with ISO4179.
e.External coating: sprayed metallic Zinc coating (min.130g/m2)according to ISO8179 + bitumen painting (min.70micron).
|
|
DN | DE1 | Iron wall thickness,e, K9 |
| 80 | 98 | 6 | |
| 100 | 118 | 6 | |
| 125 | 144 | 6 | |
| 150 | 170 | 6 | |
| 200 | 222 | 6.3 | |
| 250 | 274 | 6.8 | |
| 300 | 326 | 7.2 | |
| 350 | 378 | 7.7 | |
| 400 | 429 | 8.1 | |
| 450 | 480 | 8.6 | |
| 500 | 532 | 9 | |
| 600 | 635 | 9.9 | |
| 700 | 738 | 10.8 | |
| 800 | 842 | 11.7 | |
| 900 | 945 | 12.6 | |
| 1000 | 1048 | 13.5 | |
| 1100 | 1152 | 14.4 | |
| 1200 | 1255 | 15.3 | |
| 1400 | 1462 | 17.1 | |
| 1500 | 1565 | 18 | |
| 1600 | 1668 | 18.9 | |
| 1800 | 1875 | 20.7 | |
| 2000 | 2082 | 22.5 | |
| 2200 | 2288 | 24.3 | |
| 2400 | 2495 | 26.1 | |
| 2600 | 2702 | 27.9 |
|
1) A tolerance of + 1 mm applies. For Other Class (K7,K8,K10,K12) and Other Joint Type (Restrained Joint), please consult us. |
Packaging:Bunches with steel belt/in bulk or as per clients' requirements
Shipping:25-30 days, depends on actual quantity
