Pvc Jacket Car Audio Amplifier Wiring Installation Kit
0GA 7*7*60/0.15 OD16MM
4GA:7*3*100/0.18 OD10MM
8GA:7*70/0.15OD6.5MM
Supply:
1- power cable
2-speaker wire
3- amplifer kit
4- fuse holder
5- RCA cable
6-cutting tools
7- terminal lugs
8-led
Sample are Free
OEM and ODM are available
Construction
Conductor: Flexible bare copper / tinned copper
Insulation: Polyester film
Sheath: Natural Rubber, Neoprene Rubber or Synthetic elastomer Sheath
Standard: VDE 0282, IEC 245-6, ISD 473, BS 638-4
Technical Data
Operating Voltage: 100V
Temperature Rating: 85℃
Insulation resistance:> 20 MOhm x Km
Minimum bend radius: 12x cable diameter
Sizes: 8 AWG - 500 MCM
Feature &Benefits
Good Flexibility, Oil Resistant, Resists Compression, Cuts and Abrasion.
Color: Red, Black, Orange, Blue Yellow, & Green
Compliances: RoHS Compliant .
Application
For the connection cable between the welding tools and welding equipment or welding wire, suitable for movable
installations in harsh conditions, such as automobiles and shipbuilding,conveyors and assembly lines, etc.
More Modles
| S/No: | Specification | Conductor | OD: | Jacket | Ω/KM |
| AS-PC-01 | 4/0AWG≈107.22mm2 | CCA TCCA Copper Tinned Copper | 19.8mm | PVC SOFT PVC Transparent SOFT Clear All The Color | 0.17 |
| AS-PC-02 | 3/0AWG≈85.01mm2 | 18.5mm | 0.21 | ||
| AS-PC-03 | 2/0AWG≈67.43mm2 | 16.8mm | 0.26 | ||
| AS-PC-04 | 1/0AWG≈53.49mm2 | 15.8mm | 0.33 | ||
| AS-PC-05 | 1AWG≈42.41mm2 | 14.5mm | 0.42 | ||
| AS-PC-06 | 2AWG≈33.62mm2 | 12.5mm | 0.53 | ||
| AS-PC-07 | 4AWG≈21.15mm2 | 10.0mm | 0.84 | ||
| AS-PC-08 | 6AWG≈13.30mm2 | 8.0mm | 1.33 | ||
| AS-PC-09 | 8AWG≈8.37mm2 | 6.7mm | 2.11 | ||
| AS-PC-10 | 10AWG≈5.26mm2 | 5.5mm | 3.36 | ||
| AS-PC-11 | 12AWG≈3.33mm2 | 4.5mm | 5.31 | ||
| AS-PC-12 | 14AWG≈2.08mm2 | 3.8mm | 8.45 | ||
| AS-PC-13 | 16AWG≈1.31mm2 | 3.2mm | 13.5 |
