Help CenterYJVD Series High-Current Cables
Product Spotlights
Related Products
1. Performance & Reliability: From "Tolerance" to "Adaptability"
1.1 Higher current density at the same cross-section, with a single cable reaching up to 3200A, which can replace multiple parallel cables. It is eddy-current free, has a large heat dissipation area, fewer joints, low temperature rise, and more stable long-term operation.
1.2 Superior protection and insulation: Combines the high current-carrying capacity of busbars with the continuous waterproof and dustproof performance of power cables, with a protection grade up to IP68. It is moisture-resistant, corrosion-resistant and high-temperature resistant, suitable for harsh scenarios such as outdoor environments, energy storage systems and chemical industries.
1.3 Flexibility: Can be folded and bent at large angles according to installation requirements, easily adapting to narrow and irregular spaces.
1.4 Vibration resistance: With inherent elasticity, it can absorb vibration during equipment operation, avoiding loosening, metal fatigue and even fracture caused by long-term vibration after traditional busbar connection.
1.5 Displacement compensation: When slight relative displacement occurs between two connected components due to temperature changes (thermal expansion and contraction) or assembly deviations, the high-current cable can offset the displacement through deformation to ensure the stability of conductive connections.
2. Cost & Energy Consumption: From "High Investment & High Maintenance" to "Cost Reduction & Efficiency Improvement"
2.1 Material and comprehensive cost: High-current cables can be directly connected to power distribution cabinets without accessories such as copper lugs, greatly reducing the cost of copper auxiliary materials. With the same current-carrying capacity, it is about 40% lighter than traditional busducts, reducing building load-bearing pressure and the usage of brackets or cable trays, improving construction efficiency, and reducing comprehensive cost by more than 10% compared with traditional schemes.
2.2 Operation and maintenance cost: No hidden dangers of multiple joints, reliable insulation and protection, basically maintenance-free, significantly reducing long-term operation, maintenance and fault losses. It features energy saving, low line loss and high power utilization efficiency, saving considerable electricity costs in long-term operation, in line with the "Dual Carbon" goals.
3. Construction & Flexibility: From "Complex Customization" to "Plug-and-Play"
3.1 Long-distance integrated laying: A single cable can reach hundreds of meters without intermediate joints, requiring no connectors or elbows, reducing fault points and suitable for long-distance wiring (e.g., factories, supercharging stations, big data centers, etc.).
3.2 Extremely simple installation: Transportable in coils, and can be quickly completed by 1-2 persons through on-site cutting, drilling and bolt fixing, without copper lugs and complex crimping, greatly shortening the construction period.
3.3 Strong adaptability: Can be flexibly bent into U-shape, L-shape, easily passing through narrow cabinets and around pipelines. No factory customization is required for renovation and capacity expansion, with high reusability.
