High temperature steam flexible metal braided hose with bell mouth internal thread connection is used in printing and dyeing industry
- 10000 Piece / Pieces per Month
- Qingdao
- T/T L/C D/P D/A Credit Card PayPal Other Cash Escrow
- 7 days
- Flange connection high pressure stainless steel metal braided hose used in industry
- Stainless steel flexible metal braided hose for automobile exhaust pipe can be customized in size and length
- High temperature steam flexible metal braided hose is used in petrochemical industry
- Male connection stainless steel 304 high pressure steam metal braided hose outer braided mesh sleeve
- EPDM NR NBR rubber DIN ANIS carbon steel flange type single sphere rubber expansion joint
- DIN ANIS JIS SS304 flange type double sphere rubber expansion joint EPDM NR NBR rubber
Product Details
Brand Name: | JIEYI | Place of Origin: | China | Model Number: | FF15-01 metal braided hose |
Certification: | ISO | Thickness: | 1 ~ 3 mm | Type: | Seamless |
Application: | Steel industry, petrochemical industry, electric heating industry, transportation industry, medical and health industry | Standard: | ASTM, AISI, DIN, EN, GB, JIS | Outer Diameter: | DN15 |
Welding Line Type: | Spiral Welded | Steel Grade: | 300 Series |
Product Description
High temperature steam flexible metal braided hose with bell mouth internal thread connection is used in printing and dyeing industry
Metal hose products include oil and suction hoses, steam hoses, sandblasting hoses, acid and alkali suction hoses, food hoses, oxygen blowing hoses and various special-shaped hoses. It is widely used in machinery, chemical, petroleum, metallurgy, food and other industries.
Material
Inner Core: Corrugated Stainless Steel
•Flexible metal hose stainless steel core strengths are available in 304, 321 and 316L stainless steel
•Stainless steel tubing formed into corrugations parallel to one another
•Helical / Convoluted option available upon request
Outer Core:Braided Stainless Steel Layers
•Purchase corrugated core hose with no layers, single or double braided
•Flexible metal hose outer braid layers made from 304 stainless steel.
Use parameters | |
Pressure | 60 bar / 6.0 MPa |
Temperature | 300 ℃ / 572 °F |
Lenght | Customized |
Media | Water, Steam, Hot oil |
Size | 1/4'' ~ 10''; customized |
Connection | Thread |
Thread port | Female X Female |
Standard | BSPP/G, BSPT/Rc, NPT |
Material | SS304 |
Product name | High temperature metal hose |
What is the features of our metal flexible hose?
1.Bend easily and easy to install.
2.It is able to bear corrosion resistance and heat resistance strongly, stainless steel materials can be used safely for years .
3.Outside is covered with stainless steel wire braided ,have high bearing capacity.
4. Applied to repeated motion region in high-temperature areas, good anti-fatigue performance.
5.Diameter and length,welded on the end of hose can be produced as customer's requirement.a variety of end fitting configurations such as threaded(both NPT and BSP);fixed and floating flanges(stainless steel and carbon steel);welding neck connection and quick fittings.
To properly design a metal hose assembly for a particular application, the following design parameters must be determinde:
1. Temperature-----You should provide us information as the temperature to which the assembly is exposed a
proper fit.
2. Size-----The diameter of the connections in which the assembly will be installed is needed to provide.
3. Media-----This is improtant since you must be sure that the assembly's components are chemically
compatible with the media going through the hose as well as the environment in which the hose is installed.
4. Pressure-----identify the internal pressure to which the assembly will be exposed. This information is
important to determine if the assembly is strong enough for the application.
5. Indenify the necessary end fittings-----This is required since fittings for the assembly must be chosen to
properly fit the mating connection.
Product Show
Company Profile
Certificate
Delivery
Product packaging
Warehouse corner
Why choose us
1.Always Innovating
We have accumulated rich experirence in producing Rotary Joint,advanced equipment,advanced technology,professional staff.we keep on Innovating all the time.
2.Design Concept
Reasonable design, advanced structure,superior quality,long service life.
3.Reliable Quality
We are Alibaba Assessed Supplier,our products are certified by ISO9001,CE etc.
4.Short leading time
We have professional and advanced machines.we have 4 production line,can produce production quickly.
5.Good Price
We are crontroling each part cost so we can give customers the competitive price.
6.Internal Control
Internal inspection,all our products must be checked 3 times before packing.
7.Prompt Reply
We’ll reply your enquiry within 2 hours.
Contact us
If you have any needs, please feel free to contact us. We can produce according to your samples or drawings, we can also customize the design drawings for you according to your requirements, and then send them to you for confirmation!
