Slocable 1500V High Quality Halogen-free and UV Resistant 4.0mm2 Solar Cable Made in China
Advantages of PV Cable
- Dual wall insulation. Electron beam cross-linked
- Excellent resistance to U.V., oil, greases, oxygen, water, fluids, salt, general weathering and ozone
- Excellent resistance to abrasion
- Halogen free, flame retardant, low toxicity
- Excellent flexibility and stripping performance
- High current carrying capacity
- CE approved
Spec. of Solar Cable
|
TYPE |
Cross Section |
Wire Struct |
Conductor Diameter |
Outer Diameter |
Conductor Resistance |
Rated Voltage |
Rated Current |
|
mm2 |
No.OD (mm) |
mm |
mm |
Ω/Km |
V DC |
A |
|
|
1X2.5mm2 |
2.5 |
48XΦ0.25 |
2.0 |
5.2 |
8.06 |
1000/1500V |
30 |
|
1X4.0mm2 |
4.0 |
56XΦ0.30 |
2.6 |
6.2 |
4.97 |
1000/1500V |
50 |
|
1X6.0mm2 |
6.0 |
81XΦ0.30 |
3.3 |
7.2 |
3.52 |
1000/1500V |
70 |
|
1X10mm2 |
10 |
74XΦ0.40 |
4.4 |
8.3 |
2.12 |
1000/1500V |
95 |
|
2X2.5mm2 |
2.5 |
48XΦ0.25 |
2.0 |
6.2*9.90 |
8.06 |
1000/1500V |
30 |
|
2X4.0mm2 |
4.0 |
56XΦ0.30 |
2.6 |
6.9*11.30 |
4.97 |
1000/1500V |
50 |
|
2X6.0mm2 |
6.0 |
81XΦ0.30 |
3.3 |
7.1*14.50 |
3.52 |
1000/1500V |
70 |
Technical Data of Solar Cable
|
Certificate |
CE |
|
Conductor Material |
Class5, tinned copper |
|
Insulation Material |
XLPE |
|
Rated Voltage |
1000V / 1500V DC |
|
Range of Nominal Cross Section |
2.5--10mm2 |
|
Standard of Solar Cable |
TUV 2PfG 1169/IEC |
|
Temperature Range |
-40℃~+90°C |
|
Flame Test Standard |
DIN EN50265-2-1 UL 1571(VW-1). |
|
Smallest Permissible Bending Radius |
5XD |
|
Color of Solar Cable |
Black/Red |
|
Packing of Solar Cable |
250 meter/roll for small size, wooden drum for big size, or as per requirement |
|
Delivery Time |
According to the order (3-10 working days) |
|
Application of Solar Cable |
These cables are used for solar power plant, solar energy power station. |
Pictures of Solar Cable
Packing of Solar Cables
Carton package for DHL/FedEx/UPS:
|
Types |
Roll |
N.W |
Carton measure |
Package |
G.W. |
|
2.5mm2 |
250m/roll |
12.5kg |
360*360*320mm |
2 rolls/carton |
26kg |
|
4.0mm2 |
250m/roll |
17kg |
360*360*320mm |
2 rolls/carton |
35kg |
|
6.0mm2 |
100m/roll |
20kg |
300*300*320mm |
2 rolls/carton |
41kg |
