UL6 C80.1 Rsc Conduit Pipe
US$ 600 - 800
MOQ: 20 Metric Tons
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Secondary Or Not:
Non-secondary
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Galvanized Rigid Steel Conduit ul Listed UL6--ANSI C80.1US$ 600 - 800MOQ: 6 Metric Tons -
Hdg Rmc Conduit Pipe With ul ApprovalUS$ 600 - 800MOQ: 10 Metric Tons
-
Galvanized Erw Steel Conduit Ul6 TubeUS$ 600 - 800MOQ: 10 Metric Tons
-
Galvanized Rigid Steel Conduit ElbowUS$ 0.5 - 2MOQ: 1000 Pieces
-
Conduit Electrical FittingUS$ 0.5 - 2MOQ: 1000 Pieces
Place of Origin
Shandong, China
Secondary Or Not
Non-secondary
| Product Information | |||||
| Product Name : | rsc conduit UL6 C80.1 ; | ||||
| Standard: | UL6 & ANSI C80.1; File No.:E308290; | ||||
| Tade Size : | from 1/2" to 6"; | ||||
| Both Ends: | threaded both ends with one coupling and plastic cap; | ||||
| Length: | 3050mm or according to customer's requirement; | ||||
| Usage: | through the electrical wires with the purpose of protection for the electrical raceway system; | ||||
| Surface Finished: | Hot dip galvanized(HDG); | ||||
| Material : | carbon steel coil; | ||||
| Package: | the conduits coverd with pvc paper then tied with steel straps; | ||||
| Delivery Time: | 20 to 30 days after we receive your advance payment or copy of L/C; | ||||
| Payment Term: | L/C at sight or T/T; | ||||
Dimension and Weight Chart
| Trade Size | Nominal Wt. per 100Ft(30.5M) | Nominal Outside Diameter | Nominal Wall Thickness | ||||
| U.S. | Metric | Lbs | Kg | In. | mm | In. | mm |
| 1/2" | 16 | 82 | 37.2 | 0.84 | 21.3 | 0.104 | 2.64 |
| 3/4" | 21 | 109 | 49.44 | 1.05 | 26.7 | 0.107 | 2.72 |
| 1" | 27 | 161 | 73.03 | 1.315 | 33.4 | 0.126 | 3.20 |
| 1-1/4" | 35 | 218 | 98.88 | 1.66 | 42.2 | 0.133 | 3.38 |
| 1-1/2" | 41 | 263 | 119.3 | 1.9 | 48.3 | 0.138 | 3.51 |
| 2" | 53 | 350 | 158.76 | 2.375 | 60.3 | 0.146 | 3.71 |
| 2-1/2" | 63 | 559 | 253.56 | 2.875 | 73 | 0.193 | 4.90 |
| 3" | 78 | 727 | 329.77 | 3.5 | 88.9 | 0.205 | 5.21 |
| 3-1/2" | 91 | 880 | 399.17 | 4 | 101.6 | 0.215 | 5.46 |
| 4" | 103 | 1030 | 467.21 | 4.5 | 114.3 | 0.225 | 5.72 |
| 5" | 129 | 1400 | 635.04 | 5.563 | 141.3 | 0.245 | 6.22 |
| 6" | 155 | 1840 | 834.62 | 6.625 | 168.3 | 0.266 | 6.76 |
Applicable tolerances:
Length: 10Ft (3.05m) ± ¼” (±6.35mm).
Outside Diameter: ½”-2” ±0.015” (±0.38mm); 2½”-4” ±0.025” (±0.64mm); 5”-6” ± 1%
