High strength steel EMT pipe UL797 conduit with smooth interior surface for wiring works
- 500 Metric Ton / Metric Tons per Month
- QINGDAO TIANJIN SHANGHAI
- T/T Credit Card
Product Details
| Place of Origin: | Shandong, China | Certification: | UL | Thickness: | 1.07, 2.11 |
| Surface Treatment: | Galvanized | Technique: | ERW | ||
| Alloy Or Not: | Non-alloy | ||||
| Outer Diameter: | 17.93 - 114.3 mm | Secondary Or Not: | Non-secondary | Special Pipe: | EMT Pipe |
| Section Shape: | Round |
Product Description
Electrical Metallic Tubing (EMT)
General
EMT is manufactured from high-strength steel coil, and produced according to the standard of ANSI C80.3(UL797). The interior surface of our conduit is free from defect with a smooth welded seam. It is hot dipped galvanized inside and outside, so that metal-to-metal contact and galvanic protection against corrosion are provided, and the surface of the conduit is coated with a clear lacquer coating to inhibit white rust and increase corrosion resistance. The interior surface provides a smooth continuous raceway for easy wire pulling. Our EMT conduit has excellent ductility, providing for uniform bending and cutting.
- Length: 3050mm or according to customer’s requirement
- Usage: Through the electrical wires with the purpose of protection for the electrical raceway system
- Surface finished: Hot Dip Galvanized(HDG).
- Material : Carbon Steel Coil
- Package: The conduits coverd with pvc paper then tied with steel straps
- Delivery time: 20 to 30 days after we receive your advance payment or copy of L/C
- Payment Term: L/C at sight or T/T
Nominal Wall Thickness | |||||||
U.S. | Metric | Lbs | Kg | In. | mm | In. | mm |
16 | 30 | 13.5 | 0.706 | 17.93 | 0.042 | 1.07 | |
3/4 | 21 | 46 | 20.7 | 0.922 | 23.42 | 0.049 | 1.24 |
1 | 27 | 67 | 30.6 | 1.163 | 29.54 | 0.057 | 1.45 |
1-1/4 | 35 | 101 | 45.6 | 1.510 | 38.35 | 0.065 | 1.65 |
1-1/2 | 41 | 116 | 52.8 | 1.740 | 44.20 | 0.065 | 1.65 |
2 | 53 | 148 | 67.2 | 2.197 | 55.80 | 0.065 | 1.65 |
2-1/2 | 63 | 216 | 97.9 | 2.875 | 73.03 | 0.072 | 1.83 |
3 | 78 | 263 | 119.3 | 3.500 | 88.90 | 0.072 | 1.83 |
3-1/2 | 91 | 349 | 158.3 | 4.000 | 101.60 | 0.083 | 2.11 |
4 | 103 | 393 | 178.3 | 4.500 | 114.30 | 0.083 | 2.11 |
Length: 10Ft (3.05m) ± ¼” (±6 mm).
Outside Diameter: ½”-2” ±0.005” (±0.13mm); 2½” ±0.010” (±0.25mm); 3” ±0.015” (±0.38mm); 3½”-4” ±0.020” (±0.50mm)
Weifang East Steel Pipe Co., Ltd is nearly about 60 years old and located in the worldly kite capital -Weifang city in Shandong Province, which is about 156 kilometers far from Qingdao port. It was originated from the socialism cooperative in 1954, then developed into the state-owned enterprise, which was named as Weifang Steel Pipe company in 1976. In 2001, Weifang Steel Pipe company was restructured to be the private enterprise and renamed as Weifang East Steel Pipe Co.,Ltd.
Weifang East Steel Pipe Co.,Ltd, which occupies about 254,000 square meters, has a total capital of USD80 million and annual comprehensive output of 200,000 tons. Now it owns 800 employees, including 300 senior/intermediate engineers and professional technicians.
Now our electrical products include Rigid Steel Conduit ,Rigid Aluminum Conduit, IMC Conduit, EMT Conduit and Conduit fittings such as elbow, nipple, coupling, etc., and our products have been exported to more than 51 countries in the world, including North America, Middle America, South America, Asia, Middle East, Europe, etc. We are always appreciated by our clients for good quality and excellent services.
- Fast Facts About Weifang East Steel Pipe Co.,Ltd.
-The largest rigid steel conduit producer in China
-The only producer of Hot Dip Galvanized EMT conduit in the world.
-The professional manufacturer of conduit accessories in China
Q1. Are you a manufacturer or trading company?
A: We are a manufacturer specializing in steel pipe related products for more than 20 years in domestic market, so we can provide products stably for a long time with lower price.
Q2.Can you provide free sample for our test?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable. You only need to bear the freight and the sample will be sent out within 7 days.
Q3. Do you have any MOQ limit for production?
A: The order quantity minimum requirement is a 20 GP container. As for our steel pipe product, we usually use container transport for lower freight.
Q4. How to proceed an order for product?
A: Firstly let us know your requirements or application.
Secondly we quote according to your requirements or our suggestions.
Thirdly buyer confirms the samples(if you need) and places deposit for formal order.
Finally we arrange the production.
Q5. Is it OK to print my logo on the product or the carton packing?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q6. How to deal with the faulty?
A: We sincerely welcome you to investigate our factory and inspect the goods. Our products are produced in strict quality control system and the defective rate is low.
Also, if you have any questions or dissatisfaction, please feel free to contact us. We will serve you as soon as possible and give you a satisfactory solution.
