Durable High Pressure Boiler Tube Carbon Steel Seamless Tube ASTM A106 Grade C.
ASME SA 106 Grade C Carbon Steel Tubes also offers some other great features such as dimensional accuracy, high performance, easy to use, and more. ASME SA 106 Carbon Steel Grade C Tubes are made by qualitative range of raw materials and are available in a broad spectrum of sizes and materials at most competitive prices. We offer ASME SA 106 Grade C Carbon Steel Pipes in divergent sizes, thicknesses, diameters and specifications to suffice the clients' piping system requirements.
Specifications : ASTM A 106, ASME SA 106
Size Range : 1/2" NB to 36" NB
Thickness : SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules
Type : Seamless / ERW / Welded / Fabricated / CDW
Length : Single Random, Double Random & Required Length, Custom Size – 12 Meter lengths
End Connections : Plain, Bevel, Screwed, Threaded
Outside Coating : Black Painting, Anti-Corrosion Oil, Galvanised Finish, Finish as per customer Requirements
ASTM A106 Gr C.
With the development of the power station, the working parameters of the boiler have been improved, especially the emergence of subcritical and supercritical boilers, which has a higher requirement for the wall thickness of the boiler tubing.
ASTM A106 Gr C is ASTM A106 steel used for large diameter and high temperature and pressure boiler and Superheater C-Mn steel. Its chemical composition is simple, similar to that of 20G steel, but the content of carbon and manganese is higher, so the yield strength is about 12% higher than that of 20G, and the plasticity and toughness are similar to 20G. Manufacturing header with A106 Gr C instead of 20G (economizer, water cooling wall, low temperature superheater and reheater header) can reduce the wall thickness of about 10%, which can save the cost of materials, but also reduce the workload of welding, improve the heat transfer condition of boiler. It's working pressure is 6 ~ 13.9MPa and steam temperature is 450~580 degrees.
Standards.
ASTM A106 --Standard Specification for Seamless Carbon Steel Pipe for High-Temperature Service
ASTM A335 --Standard Specification for Seamless Ferritic Alloy-Steel Pipe for High-Temperature Service
Application.
For the high-pressure boiler and steam pipes, and the petrochemical industry pipes;
Power plant; Chemical Fertilizer; Petrochemicals; Offshore Oils; Gas Productions; Refineries and etc.
