15MO3 STEEL SHEET/PLATE
Liaocheng City Kuncheng Steel Pipe Co., Ltd. is one of DIN 15MO3 steel suppliers. We have much experience in manufacture DIN 15MO3 steel. The fastest delivery time with competitive price can be directly offer from our company. If you need know more about the steel grade feature. We can provide DIN 15MO3 chemical composition and DIN 15MO3 mechanical properties as below:
15Mo3 steel is a DIN specified pressure vessel grade chrome molybdenum steel alloy for use in elevated working temperatures.
15Mo3 steel is used as a weldable steel in the fabrication of industrial boilers and steel pressurised vessels found in the oil, gas and chemical industry. Due to the materials chrome and molybdenum content, 15Mo3 steel has excellent heat resistance and corrosion resistant characteristics.
15Mo3 DIN 17155 Number:1.5415 |
Comparision of steel grades |
|
EN 10028-2 |
16 Mo 3 |
|
NFA 36-205 |
15 D3 |
|
UNI 5869 |
15 Mo 3 |
|
BS 1501 |
1503 - 243 B |
|
UNE 36087 |
16 Mo 3 |
|
ASTM |
A 204 Gr. B |
|
JIS G3115 |
- |
|
DIN 15Mo3 steel Chemical Composition
Grade |
C. max |
Mn. |
S. |
N |
Cu |
Si. |
P. |
Cr. |
Ni. |
Mo. |
15Mo3 |
0.12- 0.2 |
0.40- 0.90 |
0.01 |
0.012 |
0.30 |
0.35 |
0.025 |
0.30 |
0.30 |
0.25- 0.35 |
DIN 15Mo3 steel Merchanical Propertites
Grade |
Tensile Strength |
Yield Strength |
Elongation in 100-150 mm(%) |
Elongation in |
Max Thickness |
15Mo3 |
440-590 |
220-275 |
19 |
24 |
250 |
If you have any new inquiry about DIN 15MO3 steel, please feel free to Liaocheng City Kuncheng Steel Pipe Co., Ltd. Your inquiry will be feedback within 12 hours. We are looking forward to cooperating with you, and welcome your inquiry!
