ASTM B231 Aluminum Stranding Wire Cable Overhead AAC Bare Conductor

ASTM B231 Aluminum Stranding Wire Cable Overhead AAC Bare Conductor thumbnail-1
ASTM B231 Aluminum Stranding Wire Cable Overhead AAC Bare Conductor thumbnail-2
ASTM B231 Aluminum Stranding Wire Cable Overhead AAC Bare Conductor thumbnail-3
ASTM B231 Aluminum Stranding Wire Cable Overhead AAC Bare Conductor thumbnail-4
ASTM B231 Aluminum Stranding Wire Cable Overhead AAC Bare Conductor thumbnail-5
ASTM B231 Aluminum Stranding Wire Cable Overhead AAC Bare Conductor thumbnail-6
ASTM B231 Aluminum Stranding Wire Cable Overhead AAC Bare Conductor thumbnail-7
ASTM B231 Aluminum Stranding Wire Cable Overhead AAC Bare Conductor photo-1
ASTM B231 Aluminum Stranding Wire Cable Overhead AAC Bare Conductor photo-2
ASTM B231 Aluminum Stranding Wire Cable Overhead AAC Bare Conductor photo-3
ASTM B231 Aluminum Stranding Wire Cable Overhead AAC Bare Conductor photo-4
ASTM B231 Aluminum Stranding Wire Cable Overhead AAC Bare Conductor photo-5
ASTM B231 Aluminum Stranding Wire Cable Overhead AAC Bare Conductor photo-6
ASTM B231 Aluminum Stranding Wire Cable Overhead AAC Bare Conductor photo-7
US$ 1 - 5 MOQ: 1000 Meters
Key Specifications
Get Latest Price
Brand Name:
RMJT
Place of Origin:
Henan, China
Model Number:
AAC
Contact Supplier Request Quote Chat Now
People\'s Cable Group Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QingDao ShangHai Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name RMJT
Place of Origin Henan, China
Model Number AAC
Type High Voltage
Application Overhead



Product Description

 Description of ASTM B231 Aluminum stranding wire cable overhead AAC bare conductor





AAC bare conductor is widely used in Transmission and distribution of electric power having medium breaking load & span runs, and it is one of the main products to form electrified wire network.



For use in overhead transmission and distribution systems, and as bus connections in substations and switchyards. Solid conductors used for mechanical and grounding applications.





Overhead bare condutor for power transmission line.
Simple structure, low cost and easy maintenance


Applications of ASTM B231 Aluminum stranding wire cable overhead AAC bare conductor

AAC (all aluminum conductor)  is widely used in power transmission lines of various rated voltage due to its simple structure, low cost and easy maintenance.
ASTM B231 Aluminum stranding wire cable overhead AAC bare conductor

1. Specification:



Code Name AWG or MCM Total Area Stranding and wire diameter Approximate Overall Diameter Linear Mass Nominal breaking Load Maximum Resistance at 20 ℃
mm2 mm mm kg/km daN Ω/km
Peachbell 6 13.29 7/1.554 4.67 37 249 2.1692
Rose 4 21.16 7/1.961 5.89 58 396 1.3624
Iris 2 33.61 7/2.474 7.42 93 597 0.8577
Pansy 1 42.39 7/2.776 8.33 117 732 0.6801
Poppy 1/0 53.48 7/3.119 9.36 147 873 0.539
Aster 2/0 67.42 7/3.503 10.51 186 1100 0.4276
Phlox 3/0 85.03 7/3.932 11.8 234 1347 0.339
Oxlip 4/0 107.23 7/4.417 13.26 296 1698 0.2688
Valerian 250 126.71 19/2.913 14.57 349 2062 0.2275
Sneezewort 250 126.71 7/4.80 14.4 349 2007 0.2275
Laurel 266.8 135.16 19/3.01 15.05 373 2200 0.2133
Daisy 266.8 135.16 7/4.96 14.9 373 2141 0.2133
Peony 300 152 19/3.193 15.97 419 2403 0.1896
Tulip 336.4 170.45 19/3.381 16.91 470 2695 0.1691
Daffodil 350 177.35 19/3.447 17.24 489 2804 0.1625
Canna 397.5 201.42 19/3.673 18.36 555 3184 0.1431
Goldentuft 450 228 19/3.909 19.55 629 3499 0.1264
Syringa 477 241.68 37/3.882 20.19 666 3849 0.1193
Cosmos 477 241.68 19/4.023 20.12 666 3708 0.1193
Hyacinth 500 253.35 37/2.951 20.65 698 4035 0.1138
Zinnia 500 253.35 19/4.12 20.6 698 3888 0.1138
Dahlia 556.5 282 19/4.346 21.73 777 4327 0.1022
Mistletoe 556.5 282 37/3.114 21.79 777 4362 0.1022
Meadowsweet 600 304 37/3.233 22.63 838 4703 0.0948
Orchid 636 322.25 37/3.33 23.31 888 4985 0.0894
Heuchera 650 329.4 37/3.37 23.59 907.4 5170 0.0875
Flag 700 54.71 61/2.72 24.48 978 5146 0.0813
Verbena 700 354.71 37/3.493 24.45 978 5487 0.0813
Nasturtium 715.5 362.58 61/2.75 24.76 1000 5874 0.0795
Violet 715.5 362.58 37/3.533 24.74 1000 5609 0.0795
Cattail 750 380 61/2.817 25.35 1048 5985 0.0759
Petunia 750 380 37/3.617 25.32 1048 5875 0.0759
Lilac 795 402.84 61/2. 90 26.11 1111 6345 0.0715
Arbutus 795 402.84 37/3.724 26.06 1111 6232 0.0715
Snapdragon 900 456.06 61/3.086 27.78 1257 6978 0.0632
Cockscomb 900 456.06 37/3.962 27.73 1257 6848 0.0632
Goldenrod 954 483.42 61/3.177 28.6 1333 7896 0.0596
Magnolia 954 483.42 37/4.079 28.55 1333 7258 0.0596
Camellia 1000 506.71 61/3.251 29.36 1397 7753 0.0569
Hawkweed 1000 506.71 37/4.176 29.23 1397 7608 0.0569
Larkspur 1033.5 523.68 61/3.307 29.76 1444 8012 0.055
Bluebell 1033.5 523.68 37/4.244 29.723 1444 7863 0.055
Marigold 1113 563.93 61/3.432 30.89 1555 8628 0.0511
Hawthorn 1192.5 604.26 61/3.551 31.05 1666 9245 0.0477
Narcissus 1272 644.51 61/3.668 33.02 1777 9861 0.0477
Columbine 1351.5 684.84 61/3.78 34.01 1888 10478 0.0421
Carnation 1431 725.1 61/389 35.03 1999 10768 0.0398

2. Standard:

1. B-230 Aluminum Wire, 1350-H19 for Electrical Purposes.

2. B-231 Aluminum Conductors, Concentric-Lay-Stranded.



Construction:



1) Conductor: 1350 Aluminum



2) Sectional area: 10-1000mm2



3) No. of strands (al/st): 7, 19, 37, 61, 91



4) Min. bending radius: 40 times cable radius



ASTM B231 Aluminum stranding wire cable overhead AAC bare conductorASTM B231 Aluminum stranding wire cable overhead AAC bare conductor



company information.

Our factory People`s Cable Group ,.Ltd., is a China non-aera group company,providing professional

manufacturing, R&D and sale of cables and wires.Now it has five core subsidiaries, with more than 80

cooperative enterprise and over 100 sales outlets in our country.Our products have been exported to

more than 80 countries,such as Southeast Asia, the Middle East ,Africa,South America and korea

Specialized in manufactured high, medium and low voltage XLPE ,fire-resisitant cable,flame-retardant

cable,control cable,rubber cable, Insulated aerial cables,shielded cable,bare aluminum conductor

ACSR,AAC AAAC ACAR  and ABC cabl
