ASTM B399 927.2MCM overhead bare aluminum alloy AAAC Greeley conductor

ASTM B399 927.2MCM overhead bare aluminum alloy AAAC Greeley conductor

1.Applications

AAAC Greeley conductor is used as bare overhead conductor for primary and secondary distribution. Designed utilizing a high-strength aluminum alloy to achieve a high strength-to-weight ratio; affords better sag characteristics. Aluminum alloy gives AAAC greeley conductor higher resistance to corrosion than ACSR.

2.Construction

Standard 6201-T81 high strength aluminum conductors, conforming to ASTM Specification B-399, are concentric-lay- stranded, similar in construction and appearance to 1350 grade aluminum conductors.

Standard 6201 alloy conductors aaac greeley conductor are similar to other alloy conductors commercially known as Ardival, Aldrey or Almelec. They were developed to fill the need for an economical conductor for overhead applications requiring higher strength than that obtainable with 1350 grade aluminum conductors, but without a steel core. The DC resistance at 20°C of the 6201-T81 conductors and of the standard ACSRs of the same diameter are approximately the same. Conductors of the 6201-T81 alloys are harder and, therefore, have a greater resistance to abrasion than conductors of 1350-H19 grade aluminum.

AAAC Greeley conductor drawing picture

3.Specifications

AAAC greeley conductor bare conductor meets or exceeds the following ASTM specifications : B-398 Aluminum Alloy 6201-T81 Wire for Electrical Purposes B-399 Concentric-Lay-Stranded 6201-T81 Aluminum Alloy Conductors

Notes

• Resistance is calculated using ASTM standard increments of stranding and metal conductivity of 52.5% IACS, AC resistance at 60Hz
• Current ratings are based on 75^oC conductor temperature, 25^oC ambient, 2ft/s wind, 96/watts/sq.ft sun, 0.5 coefficients of emissivity and absorption.

 4.Specification

 AAAC Greeley conductor

Package in wooden drum and iron wooden drum for AAAC Greeley conductor

Workshop and machines for aaac greeley conductor

About company

Welcoming visiting factory

Delivery for aaac greeley conductor

FAQ:

(1).When can I get the price?

     We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, please

call us or tell us in your e-mail so that we will regard your inquiry priority.

(2).How can I get a sample to check your quality?

     After price confirmation, you can require for samples to check our quality. Sample is free, but the freight

charge should be paid.

(3).How long can I expect to get the sample?

     After you pay the freight charge and send us confirmed files,  the samples will be ready for delivery in 3-7

days. The samples will be sent to you via express and arrive in 3-5 days. You can use your own express account orprepay us if you do not have an account.

(4).What about the lead time for mass production?

     Honestly, it depends on the order quantity and the season you place the order.The best record we keep is

delivering 10 kilometers cable within a week. Generally speaking, we suggest that you start inquiry two months

before the date you would like to get the products at your country.
