electric cable sizes 18awg pvc insulation VV nyy cable

FOB Price

USD $0.07 - $1.79 / Meter

500 Meters(Min.Order)

Supply Ability 2147483647 Meter / Meters per Month
Port Qingdao Shanghai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	RMjT	Place of Origin	Henan, China
Model Number	electrical wire
Insulation Material	PVC
Conductor Material	Copper

Product Description

_{Product Construction}

^{1.Conductor : bare/tinned copper,or Aluminum.
2.Insulation : PVC rated at 70°C
3.Color Code : red,orange,yellow,yellow-green,blue,purple,gray,white or as your requirement
4.Outer sheath : PVC tapes ST2 to IEC.}

Service Performance Of Copper Wire

^{1. Rated voltage : 300/300V ; 300/500V ;450/750V
2. Long-term working temperature : not be higher than 70°C
3. When laying the cable, the ambient temperature should not lower than 0°C
4. Minimum bending radius : Bending radius ≥ 4D as cable overall diameter ≤ 25mm; Bending radius ≥ 6D ascable overall diameter > 25mm.}

No.	Type	Description
1	60227 IEC 01(BV)	Single core rigid conductor unsheathed cable _{for general purposes(H07V-U or H07V-R)}
2	60227 IEC 02(RV)	Single core flexible conductor unsheathed cable _{for general purposes(H07V-K)}
3	60227 IEC 05(BV)	Single core 70℃ solid conductor unsheathed cable _{for internal wiring(H05V-U or H05V-R)}
4	60227 IEC 06(RV)	Single core 70℃ flexible conductor unsheathed cable _{for internal wiring(H05V-K)}
5	60227 IEC 07(BV-90)	Single core 90℃ solid conductor unsheathed cable _{for internal wiring(H07V-U or H07V-R)}
6	60227 IEC 08(RV-90)	Single core 90℃ flexible conductor unsheathed cable _{for internal wiring(H07V-K)}
7	60227 IEC 10(BVV)	Light PVC sheathed cable(NYY or NYM)
8	60227 IEC 42(RVB)	Flat unsheathed flexible wire
9	60227 IEC 52(RVVB, RVV)	Light PVC sheathed flexible copper wire _{(H03VV-F,H03VVH2-F)}
10	60227 IEC 53(RVVB, RVV)	Common PVC sheathed flexible copper wire _{(H05VV-F,H05VVH2-F)}
11	BV	Copper conductor PVC insulated wire(H07V-U or H07V-R)
12	BLV	Aluminum conductor PVC insulated wire
13	BVR	Copper conductor PVC insulated flexible cable(H07V-R)
14	BVV	Copper conductor PVC insulated sheathed _{circular cable(NYY or NYM)}
15	BLVV	Aluminum conductor PVC insulated and sheathed round cable
16	BVVB	Copper conductor PVC insulated and sheathed flat cable
17	BLVVB	Aluminum conductor PVC insulated sheathed flat cable
18	NMD	Copper conductor PVC/Nylon Insulated PVC Jacked flat cable
19	RVS	Twisted copper conductor PVC insulated flexible cable for conection
20	AVP	Copper conductor PVC insulated wire with shield for installation
21	RVP	Copper conductor PVC insulated flexible wire with shield
22	RVVP	Copper conductor PVC insulated, shielded, _{PVC sheathed flexible cable}
......

Specification for BV BLV electrical wire cable

_{Nominal sectional area mm2}	_{Conductor No/Dia. Mm}	_{Nominal Insulated thick mm}	_{Max overall Dia. Mm}	_{Condcutor Resistance at 20}			_{Min insulated resistance at 70MΩ/km}	_Weight _Kg/km
_{Nominal sectional area mm2}	_{Conductor No/Dia. Mm}	_{Nominal Insulated thick mm}	_{Max overall Dia. Mm}				_{Min insulated resistance at 70MΩ/km}		Cu	Al	_Cu	_Al
1.5	1/1.38	0.7	3.3	12.1	-	0.011	19.2	-
1.5	7/0.52	0.7	3.5	12.1	-	0.01	20.6	-
2.5	1/1.78	0.8	3.9	7.41	11.8	0.01	30.8	15
4	1/2.25	0.8	4.4	4.61	7.39	0.0085	45.5	21
6	1/2.76	0.8	4.9	3.08	4.91	0.007	65	29
10	7/1.35	1	7	1.83	3.08	0.0065	110	52
16	7/1.70	1	8	1.15	1.91	0.005	170	70
25	7/2.14	1.2	10	0.727	1.2	0.005	270	110
35	7/2.52	1.2	11.5	0.524	0.868	0.004	364	150
50	19/1.78	1.4	13	0.387	0.641	0.0045	500	200
70	19/2.14	1.4	15	0.268	0.443	0.0035	688	269
95	19/2.52	1.6	17.5	0.193	0.32	0.0035	953	360
120	37/2.03	1.6	19	0.153	0.253	0.0032	1168	449
150	37/2.25	1.8	21	0.124	0.206	0.0032	1466	551
185	37/2.52	2	32.5	0.099	0.164	0.0032	1808	668

Attention: We can provide more information than above data, if needed.The above are just some examples.

Packaging and delivery

Our Company

^{People's Cable Group Co., Ltd.}

^{People's Cable Group Co., Ltd. Was founded in 2007, with good transport facilities which adjacent to the 310 national highway-Lian Huo highway. Our company had 2 factories(Zhitian factory and Zhulin factory), occupies total area of more than 300,000 square meters, with building area 230,000 square meters. The real capital assets more than 10 million USD, with 630 staff members, 65 of which are professional and technical experts.}

^{Our mainly products as follow:}

^{1.PVC insulated electric wire whatever copper conductor,aluminum conductor,CCA(copper clad
aluminum),CCS(copper clad steel).
2.PVC insulated power cable and xlpe insulated power cable with or without armor upto 35kv.
3.Rubber cable like welding cable, mining cable, control cable and so on.
4.Aerial bundled cable(ABC cable) up to 10kv, like Duplex ABC cable, Triplex ABC cable, Quadruplex ABC cable and so on.
5.Bare conductor like AAC, AAAC, ACSR, AACSR, ACAR, ACSR/AW, aluminum clad steel wire, galvanized steel wire and so on.}

Our clients

Our certification

FAQ

^{Q1: When can I get the price?
We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in
your email so that we will regard your inquiry priority.
Q2: How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. Sample is free, but the freight charge should be paid.
Q3: How long can I expect to get the sample?
After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7 days.
The samples will be sent to you via express and arrive in 3~5 days.
Q4: What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order.The best record we keep is delivering 10 kilometers cable within a week. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.}
