For MOOG servo valve D663-4006

Name: For MOOG servo valve D663-4006
Brand: MO-OG
Price: USD $100 - 101 / Set

FOB Price

USD $100 - $101 / Set

1 Set(Min.Order)

Supply Ability 10 Set / Sets per Month
Port Any port
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:

MO-OG

Product Description

D660 series servo proportional control valve is used in two-way, three-way, four-way and five way throttle type flow control valve. These valves are suitable for electro-hydraulic position, speed, pressure or electro-hydraulic control system, as well as other control occasions requiring high dynamic response requirements. The control circuit in D660 series valve is also an innovation of our company. It adopts SMD technology and 24VDC power supply.

Technical Parameters

Model... Type				D661-P/B...A	D661-P/B...B
Installation form	Meet ISO standard, one more t port			ISO 4401-05-05-0-05
Types of valves				"Four way, 2 * 2 way and five way The second stage is the standard slide valve“
Pilot valve	ServoJet			Standard flow rate	Large flow rate
Pilot connection	Internal control (row) or external control (row) can be selected**			X port and Y port	X port and Y port
weight			KG（1b)	5.6（12.3）	5.6（12.3）
Rated discharge	（±10%）△PN=5bar（75psi)/ Every throttling edge“	1/min (gpm)	30/60/80/280 （7.9、15.9、12.1、221.1）	30/60/80/280 （7.9、15.9、12.1、221.1）
Working pressure	Maximum
Main valve	Port P, port a and port B	bar(psi)	350（5080）	350（5080）
		Port t (inner row of port y)	bar(psi)	210（3050）	210（3050）
		Port t (outlet y)	bar(psi)	350（5080）	350（5080）
Pilot valve	standard	bar(psi)	280（4060)	280（4060)
		With pressure reducing orifice	bar(psi)	350(5080)	350(5080)
		(selected according to user requirements)
Response time*	0-100% spool displacement, typical	ms	28	18
Minimum resolution*			%	<0.05	<0.05
Hysteresis *			%	<0.3	<0.3
Zero drift	△T=55K	%	<0.1	<0.1
Zero leakage*	Total leakage (~ zero cover)	1/min(gpm)	3.5(0.9)	4.4(1.2)
Pilot leakage*	Pilot valve only, typical	1/min(gpm)	1.7(0.5)	2.6(0.7)
Pilot flow	Maximum flow under full open step signal input	1/min(gpm)	1.7(0.5)	2.6(0.7)
Stroke of main valve element			mm(in)	±3（0.1）	±3（0.1）
Driving area of main valve element			cm2(in2)	2（0.31）	2（0.31）

Related products

Packing&Shipping

In order to ensure that the product is not damaged during transportation, we will choose to use high-hardness cardboard boxes or wooden boxes to package the product according to the volume of the product, and adopt protective measures such as foamanti-collision and wooden frame fixing to ensure the safe and non-destructive delivery of the goods to the greatest extent.
