America Servo Valve D633E714A/D633E716A
US$ 100 - 101
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
MO-OG
Pressure:
High Pressure
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
For Moog Servo Valve C05623-005US$ 100 - 101MOQ: 1 Set -
Servo Valve D634 SeriesUS$ 925 - 2,350MOQ: 1 Set
-
For MOOG D643-344 Hydraulic Valve Servo ValveUS$ 100 - 101MOQ: 1 Set
-
Proportional Servo Valve for MOOG J664-101BUS$ 100 - 101MOQ: 1 Set
-
Electro-hydraulic Servo Valve D765-1600US$ 100 - 101MOQ: 1 Set
Brand Name
MO-OG
Pressure
High Pressure
Product Description
D633 and d634 series are direct acting valves (DDV) with closed-loop position control of live feedback valve core. This valve is a throttle type flow control valve that can be applied to three-way, four-way and 2x2-way valves. They are suitable for electro-hydraulic position, velocity, pressure or force control systems and other systems requiring high dynamic response. The valve core is driven by a permanent magnet linear force motor, which can flexibly drive the valve core from the spring centering position in two directions. This is one of the advantages of the proportional solenoid valve, which can only produce one-way driving force. A closed-loop valve position control circuit board and a pulse width modulation (PWM) driving circuit are integrated in the valve.
The integrated circuit of the valve is a great development characterized by SMD technology with PWM current drive output and 24V power supply.
Technical Parameters
Model... type |
D633 |
|
Specification for installation with or without drain |
ISO 4401-03-03-0-94 |
|
Diameter of valve port |
mm(in) |
7.9(0.31) |
Valve specification |
Single stage valve, slide valve type with valve sleeve |
|
Tee, cross or 2 * 2 |
||
Driving mode of valve element |
Direct drive of permanent magnet linear force motor |
|
Pilot level |
nothing |
|
weight |
kg(ib) |
2.5（5.5） |
△ PN = rated flow (± 10%) at 35bar 「 500PSI 」 per throttling edge |
l/min(gpm) |
5/10/20/40（1.3/2.6/5.3/10.6） |
Maximum flow of valve |
l/min(gpm) |
75（19.8） |
Maximum working pressure |
||
Port P、 A 、B |
bar(psi) |
350（5000） |
Port T (internal discharge) |
bar(psi) |
50（715） |
Port T (Y port drain) |
bar(psi) |
350（5000） |
Valve port Y |
bar(psi) |
Direct return tank |
Response time (valve core 0-100% full opening) |
ms |
≤12 |
Resolving power |
% |
＜0.1 |
Hysteresis loop |
% |
＜0.2 |
Zero drift (△ t = 55k) |
% |
＜1.5 |
Maximum zero leakage (zero opening) |
l/min(gpm) |
0.15/0.3/0.6/1.2（0.04/0.08/0.16/0.32） |
