Original Hydraulic Pressure Servo Valve XWB11154-000-21

Original Hydraulic Pressure Servo Valve XWB11154-000-21 thumbnail-1
Original Hydraulic Pressure Servo Valve XWB11154-000-21 photo-1
US$ 100 - 101 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
M-O-O-G
Pressure:
High Pressure
Contact Supplier Request Quote Chat Now
Shenzhen Ou Hang Fluid Power Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name M-O-O-G
Pressure High Pressure
Product Description
"Features of xwb11154-000-21 series stable grid servo valve: high driving force with valve core Installation dimensions according to 1So 4401 (the external oil control port does not meet the relevant standards of 1s04401) Long and robust design High rate low lag loop Using dry torque motor and two-stage hydraulic amplifier structure Low friction guide stage double nozzle flapper valve (pilot stage) When leaving the factory, all the data were adjusted The pilot valve can be individually controlled by selecting the fifth port Field replaceable pilot wide disc filter "
working principle:
When the current command signal is input into the coil of the torque motor, the electromagnetic force will act on both ends of the armature, thus driving the damper in the spring tube to deflect. Deflection of the baffle will reduce the flow rate of the nozzle, thus changing the pressure on one side of the wide core connected with the nozzle and pushing the valve core to one side The displacement of the valve element opens the access between one control port and the oil supply port (P), and connects the oil circuit between the other control port and the return port (T). At the same time, the displacement of the valve core will also produce a force on the spring rod, thus forming a restoring torque to the armature baffle assembly. When the restoring torque is balanced with the torque acting on the armature damper due to the electromagnetic force of the torque motor, the damper returns to zero, and the sliding core keeps the opening position of the balance state until the given signal input changes.
Technical Parameters
Model
XWB11154-000-21
brand
MOOG
Product category
Servo valve
Related Products
Packing&Shipping
In order to ensure that the product is not damaged during transportation, we will choose to use high-hardness cardboard boxes or wooden boxes to package the product according to the volume of the product, and adopt protective measures such as foam anti-collision and wooden frame fixing to ensure the safe and non-destructive delivery of the goods to the greatest extent.
