Parker Manual Reversing Valve D41FHB32C4NS 0048

Parker Manual Reversing Valve D41FHB32C4NS 0048 thumbnail-1
Parker Manual Reversing Valve D41FHB32C4NS 0048 photo-1
US$ 100 - 101 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Parker
Model Number:
D41FHB32C4NS 0048
Power:
/
Contact Supplier Request Quote Chat Now
Shenzhen Ou Hang Fluid Power Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Parker
Model Number D41FHB32C4NS 0048
Pressure High Pressure
Product Description
D1f series pilot operated proportional directional valves of nominal sizes cetop 5 to 10 are used to control flow. The valve has integrated electronic components, and the position of the valve core of the main stage can be adjusted. Typical applications are: accurate flow control and flow regulation. In the fast and low speed operation, the valve core position monitoring is used for: press control, dynamic position regulation and pressure flow closed-loop system. Technical characteristics: - small leakage - high frequency sound, large oil capacity - accurate fault state diagnosis - mechanical zero adjustment of zero covering valve - high strength - displacement feedback of valve core position - optional spool position travel monitoring
Technical Parameters
Survey
structural style
Pilot proportional directional valve with integrated power amplifier
Operation mode
Proportional electromagnet
Installation location
Arbitrarily
ambient temperature
°C
20…+60
Hydraulic pressure
Working medium
Hydraulic oil according to din51 524 standard
Recommended viscosity
mm2/s
30…80
Maximum permissible
mm2/s
20…380
Oil temperature
°C
0…+60
filter
Allowable pollution level of working medium
As per NAS 1638
Pilot level
Level 7
Master level
Level 9
Connector
DIN 24340/ISO 4401/CETOP RP121/NFPA
Working pressure
bar
Port P, t, a, B, X Max 350bar, port y Max 10bar
Nominal size
DIN
NG10
NG16
NG25
NG32
CETOP
5
7
8
10
weight
KG
8.1
11.6
20.7
62
Rated flow, when p = 5bar
l/min
70
180
400
1000
Maximum flow rate
l/min
170
420
900
2000
Leakage oil (140bar)
l/min
0.1
0.2
0.6
1.00
