Home > Products > Proportional servo valve > America VICKERS Electro-hydraulic proportional valve KACG3 L40D Z-M3-PD7-H1-10
America VICKERS Electro-hydraulic proportional valve KACG3 L40D Z-M3-PD7-H1-10
USD $100 - $101
/ Set
1 Set(Min.Order)
- 30 Set / Sets per Month
- Any port
- T/T Credit Card
You May Like
- America VICKERS Proportional valve KBDG5V 8 2C330N X 7 M1 PC7 H1 10
- Pilot-Operated Servo valves D661Z4754
- Germany rexroth servo valve 4WSE2ED 10-51-75B9ET315K31DV
- Original new product rexroth servo valve 4WSE3EE 16-15-200B8T315K9EM use for metallurgy and steel works
- Rexroth Bosch cartridge valve FESE 63 CA-30-1800LKOB1M
- Pilot-Operated Servo valves D761-2619
Product Details
Brand Name: | VICKERS | Model Number: | KACG3 L40D Z-M3-PD7-H1-10 |
Pressure: | High Pressure |
Product Description
Product Description
An electro-hydraulic proportional current valve is designed to regulate the pressure in the hydraulic system in proportion to the added electrical input.
The open-loop single-stage valve can be used to directly control the pressure in the small flow system, and it can be used for the pilot control of the larger pressure control valve and the use of the pressure control pump.
- valve design ensures small hysteresis and good repeatability.
- automatic venting design simplifies installation and ensures consistent performance.
- when it is used to control large flow relief valve or pressure reducing valve, the minimum pressure is obtained, and the response to step input signal is fast and stable.
Technical Parameters
Maximum pressure | ||
Oil port P: | ||
work | See model compilation | |
static state | 350bar(5075psi) | |
Mouth T: | ||
work | 2bar(29 psi) | |
static state | 210bar(3000psi) | |
Flow limit: | ||
Rated discharge | 1L/min(0.26USgpm) | |
Maximum flow rate | 5L/min(1.3USgpm) | |
Coil or amplifier rating | ||
Type KCG | ||
Type KACG | 24V * 40W max (22 to 36V including 10% peak to peak maximum fluctuation) | |
Command signal range, type kacg | 0 to +10V DC, or 0 to 10V DC | |
Flutter, type KACG | Factory setting, user can't adjust | |
Monitor point signal, type KACG | 0, 5V / a electromagnet current | |
Power level PWM,KACG type | 2KHz nominal value |
Related Products
Packing&Shipping
In order to ensure that the product is not damaged during transportation, we will choose to use high-hardness cardboard boxes or wooden boxes to package the product according to the volume of the product, and adopt protective measures such as foam anti-collision and wooden frame fixing to ensure the safe and non-destructive delivery of the goods to the greatest extent.
