Application:
RHH/RHW-2/USE-2 cable is suitable for various commercial and industrial applications. These cables can be installed in wet or dry locations, indoors or outdoors, in raceways, underground ducts (ask about our pre-installed cable-in-conduit products), aerial or direct buried.
RHH/RHW-2/USE-2 cable is NEC-compliant for continuous operations at 90°C in wet and dry locations, 130° C for emergency overload conditions and 250°C for short circuit conditions.
Voltage rating for RHH or RHW-2 or USE-2 conductors is 600V.
Construction:
RHH or RHW-2 or USE-2 aluminum conductors are AA-8000 series Aluminum Alloy, compact stranded. Insulation is an abrasion, moisture, heat, and sunlight resistant black cross-linked polyethylene (XLP).
The insulation is suitable for use in wet or dry locations at a conductor temperature not exceeding 90° C for normal operation.
Specification:
Cable shall be UL-listed Type RHH or RHW-2 or USE-2,suitable for operation at 600 V or less in wet or dry locations,including direct burial in the earth.
Standard:
RHH or RHW-2 or USE-2 cable meet or exceed UL Standard 44 (for RHH or RHW-2), UL Standard 854(for USE-2), Federal Specification A-A-59544, and requirements of the NEC(National Electric Code).
Assembly:
Single conductor cables can be paralleled or multiplexed for more efficient installations. Single conductor cables can also be pre-installed in conduit.
|
CONDUCTOR SIZE (AWG or kcmil) |
INSULATION THICKNESS (mils) |
NOMINAL O.D.(mils) |
AMPACITIES*(AMPS) |
APPROXIMATE NET WEIGHT PER 1000ft(lbs) |
||
60°C |
75°C |
90°C |
||||
8 |
60 |
257 |
30 |
40 |
45 |
36 |
6 |
60 |
292 |
40 |
50 |
60 |
49 |
4 |
60 |
336 |
55 |
65 |
75 |
65 |
2 |
60 |
391 |
75 |
90 |
100 |
94 |
1 |
80 |
462 |
85 |
100 |
115 |
126 |
1/0 |
80 |
499 |
100 |
120 |
135 |
151 |
2/0 |
80 |
539 |
115 |
135 |
150 |
182 |
3/0 |
80 |
586 |
130 |
155 |
175 |
221 |
4/0 |
80 |
638 |
150 |
180 |
205 |
269 |
250 |
95 |
713 |
170 |
205 |
230 |
326 |
300 |
95 |
763 |
190 |
230 |
255 |
381 |
350 |
95 |
809 |
210 |
250 |
280 |
435 |
400 |
95 |
852 |
225 |
270 |
305 |
488 |
500 |
95 |
929 |
260 |
310 |
350 |
595 |
700 |
110 |
1100 |
310 |
375 |
420 |
829 |
750 |
110 |
1131 |
320 |
385 |
435 |
881 |
1000 |
110 |
1283 |
375 |
445 |
500 |
1145 |
