LV AMKA-T ABC cables CABLE AL XLPE LT ABC 3x95+70+1x25MM2 AAC+AAAC 0.6/1kv conductor xlpe AAC+AAAC 0.6/1kv messenger HDPE
Item name:LV IRAM ABC CABLE AL HDPE BS-JKLYJ 2*35 4*16 2*10mm AAC+AAAC 0.6/1kv messenger xlpe insulated
ABC Cable,Insulated Aerial Cable,Aerial Bundled Cable
This series includes: ABC cable, * All aluminum conductors (AAC) * All aluminum alloy conductors (AAAC) * Aluminum conductor steel reinforced (ACSR) * Anti-corrosion type ACSR * All steel conductors Relative manufacturing standards: IEC61089, ASTM B231, B232, BS215, DIN48204
| Place of Origin: Henan China (Mainland) | Brand Name: Huadong | Insulation Material: PVC |
| Type: Low Voltage | Application: Overhead | Conductor Material: Aluminum |
| Jacket: PVC |
| Packaging Detail: | wooden drum |
| Delivery Detail | one month |
ABC Cable(Aerial Bounded Cable), primarily used for 120 volt overhead service applications.
(1).Application
ABC Cable Primarily used for 120 volt overhead service applications such as street lighting,outdoor lighting,and temporary service for construction.To be used at voltages of 600 volts phase-to-phase or less and at conductor temperatures not to exceed 75oC for polyethylene insulated conductors or 90oC for crosslinked polyethylene(XLP)insulated conductors.
(2).Construction
Code Word |
Phase conductor |
Bare Neutral Messenger |
Nominal Lay Length |
Weight Per 1000ft. (lbs.) |
Allowable Ampacities+ |
|||||||
|
Size (AWG) |
Stranding |
Insul. Thick. (Mils) |
Size (AWG) |
Stranding |
Rated Strength (lbs.) |
inches |
XLP |
POLY |
XLP |
POLY |
||
AAC Neutral-messenger | ||||||||||||
Pekingese |
6 |
1 |
45 |
6 |
7 |
563 |
10.36 |
61 |
61 |
85 |
70 |
|
Collie |
6 |
7 |
45 |
6 |
7 |
563 |
10.36 |
64 |
64 |
85 |
70 |
|
Dachshund |
4 |
1 |
45 |
4 |
7 |
881 |
10.36 |
92 |
92 |
115 |
90 |
|
Spaniel |
4 |
7 |
45 |
4 |
7 |
881 |
10.36 |
96 |
96 |
115 |
90 |
|
Doberman |
2 |
7 |
45 |
2 |
7 |
1350 |
14.88 |
147 |
147 |
150 |
120 |
|
Malemute |
1/0 |
9 |
60 |
1/0 |
7 |
1990 |
14.88 |
234 |
234 |
205 |
160 |
|
Code words for XLP insulated products are formed by adding/XLPto the conventional code words above(e.g.-Chihuahua/XLP)
600/1000v Aerial Bundle Cable
1)Certificate:ISO9001
2)Fast delivery and best price
3)Standard:IEC,ASTM,BIS,etc.
LV AMKA-T ABC cables CABLE AL XLPE LT ABC 3x95+70+1x25MM2 AAC+AAAC 0.6/1kv conductor xlpe AAC+AAAC 0.6/1kv messenger HDPE .
1) Packing length:100 to 1,000m reeled in carton drum or according to customers' requirement.
2) Outer packing: wooden case, carton box.
3) Other packing requirement according to client's request.
LV AMKA-T ABC cables CABLE AL XLPE LT ABC 3x95+70+1x25MM2 AAC+AAAC 0.6/1kv conductor xlpe AAC+AAAC 0.6/1kv messenger HDPE
Henan Huadong Cable Co., Ltd is a joint stock enterprise integrated incable production, research & development,
and domestic& international trade.
Established year: 1988
Total asset: USD 32 million
Plant area: 30000 m2
Number of staff: 380
Engineer:20
Laboratory Inspector: 18
Production line: 18
Testing machine:25
Producing capacity each year: 320000 km.
LV AMKA-T ABC cables CABLE AL XLPE LT ABC 3x95+70+1x25MM2 AAC+AAAC 0.6/1kv conductor xlpe AAC+AAAC 0.6/1kv messenger HDPE Standard.
Our products are produced according to the standards of GB, IEC, BS, DIN, ASTM, JIS, NF, AS/NZS, CSA and so on.
Meanwhile we can produce based on customers' requirements and specifications.
LV AMKA-T ABC cables CABLE AL XLPE LT ABC 3x95+70+1x25MM2 AAC+AAAC 0.6/1kv conductor xlpe AAC+AAAC 0.6/1kv messenger HDPE Certification.
The company has passed ISO90012008 quality certification, CCC China Compulsory Certification, National Electrical
Product Safety Certification, State Construction and ProjectCommitee Recommended Manufacturer of the
Transformation of Urban and Rural Power Grid Construction.
LV AMKA-T ABC cables CABLE AL XLPE LT ABC 3x95+70+1x25MM2 AAC+AAAC 0.6/1kv conductor xlpe AAC+AAAC 0.6/1kv messenger HDPE
Advanced connectors & assembly cables machines and testing equipments.
Large production capacity, short delivery.
Strict QC checking before delivery.
OEM/ODM service available, help you on designing.
Prompt quotation for your inquiry.
More than 10 years experiences in cable and wire field.
Professional connector and cable manufacturer, with good quality and competitive price.
free samples are available for further evaluation and you are highly welcome to visit our factory anytime!!
Our payment term is usually T/T 30% in advanced, the balance before picking up the goods or L/C at sight.
2.what is the lead time ?
The lead time usually is 10 - 30 working days.
3.what is the package of the cable ?
The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirment.
4.Could we provide the free sample for customer ?
Sure, we provide the free sample for customer to checking.
