china avant quick coupler 4wd compact articulated Mini wheel loader with CE certification
1. Mini Loader HY200
HY200 is a versatile mini 4wd loader, articulated steering chassis, 260kg load capacity, all imported hydraulic parts, elegant design, high working performance. Widely used in garden, manufacturing, recycling, roads, buildings, construction, farms and so on. High performance earth moving machine. Standard configuration is with a standard bucket. Multifunctional attachments for optional.
2. HY200 Main Specification:
| |
1)Size | |
Dimension |
2430mm* 1080mm* 2045mm |
Length |
2430mm |
Width |
1080mm |
Height |
2045mm |
Bucket Width |
1150mm |
Max Pin Height |
1755mm |
Max Dumping Height |
1295mm |
Max Dumping Distance |
430mm |
Total Length without Bucket |
2015mm |
Turn Radius forward Turning |
2030mm |
2)Engine | |
Rated Power (KW) |
17.15KW(23HP) |
Type |
Gasoline |
3)Hydraulic System | |
Pressure |
17Mpa |
Operating Load |
260kg |
Bucket Capacity |
0.15m³ |
Travel Speed |
0-8km/h |
Weight |
900kg |
Fuel tank capacity |
27.45L |
Hydraulic oil tank capacity |
21L |
Max traction |
5KN |
Max Lifting force |
4.6KN |
4)Configuration | |
Engine |
23hp U.S Briggs & Stratton engine |
Pump, Valves, hydraulic system |
All Imported Italy brands. |
Tires |
With Lawn tires, 20*10.00-10P324P/TL |
Optional Configuration |
Electric type |
| |
3. Features | |
|
• Articulated Steering Chassis, hydrostatic transmission • Two pedals operating way, driving safety and easily. • Ergonomically designed, operation comfortably and safety. • A loader can for many purposes. Quick hitch system, you can change different attachments for different jobs quickly and easily. | |
4. Optional Attachments | |
|
| |
Located at the foot of the world famous Mount. Tai, Taian Hysoon Machinery Co., LTD is the first-class company engaged in the research, development and manufacture of miniature engineering machinery in china. Leading products are mini loaders,skid steer loaders and mini skid steer loaders. Please feel free to contact us! And welcome to visit us!
Certifications: CE, GOST,ISO9001,SGS, Design Patent,Utility Model Patent.
1). We are professional top Manufacturer of Mini Loaders in China.
4). Responsible, in Good Faith. To Guarantee Delivery. Do Security by Alibaba Onetouch.
2. Our Warranty?
1). Warranty: 1 Year. Offer You Accessories for Free in 1 Year Period.
2). Engine Warranty: 3 Years. International Warranty.
3). Provide Technical Support for Life.
3. Do We have Distributors?
Yes. In South Korea. In Australia is branch company. And we are widely recruit Distributors Around the World.
4.Can We Support OEM?
Yes, we can.
