HYSOON HY200 mini articulated loader
1. Mini Articulated Loader HY200
HY200 is a versatile mini wheel loader, articulated steering chassis, 260kg load capacity, all imported hydraulic parts, elegant design, high working performance. Widely used in gardens, manufacturing, recycling, roads, buildings, construction, farms and so on. High performance earth moving machine. Standard configuration is with a standard bucket. Multifunctional attachments for optional.
2. HY200 Mini Articulated Loader Main Specification:
| |
1)Size | |
Dimension |
2430mm* 1080mm* 2045mm |
Length |
2430mm |
Width |
1080mm |
Height |
2045mm |
Bucket Width |
1150mm |
Max Pin Height |
1755mm |
Max Dumping Height |
1295mm |
Max Dumping Distance |
430mm |
Total Length without Bucket |
2015mm |
Turn Radius forward Turning |
2030mm |
2)Engine | |
Rated Power (KW) |
17.15KW(23HP) |
Type |
Gasoline |
3)Hydraulic System | |
Pressure |
17Mpa |
Operating Load |
260kg |
Bucket Capacity |
0.15m³ |
Travel Speed |
0-8km/h |
Weight |
900kg |
Fuel tank capacity |
27.45L |
Hydraulic oil tank capacity |
21L |
Max traction |
5KN |
Max Lifting force |
4.6KN |
4)Configuration | |
Engine |
23hp U.S Briggs & Stratton engine |
Pump, Valves, hydraulic system |
All Imported Italy brands. |
Tires |
With Lawn tires, 20*10.00-10P324P/TL |
Optional Configuration |
Electric type |
| |
3. HY200 Mini Articulated Loader Features | |
|
• Articulated Steering Chassis, hydrostatic transmission • Two pedals operating way, driving safety and easily. • Ergonomically designed, operation comfortably and safety. • A loader can for many purposes. Quick hitch system, you can change different attachments for different jobs quickly and easily. | |
4. HY200 Optional Attachments | |
|
| |
LCL, steel frame & Plywood packing.
1* 20' Container: 5 sets of HY200 Mini Articulated Loaders.
1* 40'' Container: 10 sets of HY200 Mini Articulated Loaders.
Certifications: CE, GOST,ISO9001,SGS, Design Patent,Utility Model Patent.
1). We are professional top Manufacturer of Mini Articulated Loaders in China. 2). Independent of The Design Team, 15 Technical Patents. Accept Your Customization.
4). Responsible, in Good Faith. To Guarantee Delivery. Do Security by Alibaba Onetouch.
2. Our Warranty?
1). Warranty: 1 Year. Offer You Accessories for Free in 1 Year Period.
2). Engine Warranty: 3 Years. International Warranty.
3). Provide Technical Support for Life.
3. Do We have Distributors?
Yes. In Australia and South Korea. And we are widely recruit Distributors Around the World.
4.Can We Support OEM?
Yes, we can.
