Home > Metallurgy, Mineral & Energy > Steel & Products > Stainless Steel > Tisco Stainless Steel SUS316L Sheet
Tisco Stainless Steel SUS316L Sheet
US$ 2000 - 6580
MOQ: 1 Ton
Key Specifications
Get Latest Price
Brand Name:
Tisco, Baosteel, Jisco, Posco, etc.
Place of Origin:
China
Model Number:
201, 202, 301, 304, 305, 316, 316L, 317, 409, 410, 430, 441, 444, 420, 430, 420J2, 631, 630, 2205, 2207 etc.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
10 days
Related Products
-
SUS304 316 430 Rose Gold Brushed Hairline Finish Decorative Stainless Steel SheetUS$ 2000 - 6000MOQ: 1 Ton -
AISI 201 304 310S 316L 430 2205 904L Stainless Steel Sheet/Plate/Coil/StripUS$ 2000 - 8700MOQ: 1 Ton
-
Tisco Cold Rolled Stainless Steel SUS/AISI 316L SheetUS$ 2000 - 6000MOQ: 1 Ton
-
201 316 316L Ti-Golden Mirror Finish Stainless Steel SheetUS$ 2000 - 7400MOQ: 1 Ton
-
Stainless Steel Sheet for Construction Building 304, 316LUS$ 2000 - 7500MOQ: 1 Ton
Brand Name
Tisco, Baosteel, Jisco, Posco, etc.
Place of Origin
China
Model Number
201, 202, 301, 304, 305, 316, 316L, 317, 409, 410, 430, 441, 444, 420, 430, 420J2, 631, 630, 2205, 2207 etc.
Certification
SGS
Length
1000-6000mm or as requiremnt
Thickness
0.04-4mm
Type
Plate
Width
10-2000mm or as requirement
Application
medical equipment, home appliance, kitchen products,machine, engine, ect.
Standard
ASTM, AISI, DIN, EN, GB, JIS
Grade
300 Series
Product Description----------------------------------------------------------------------------------
316L stainless steel precision strip/sheet
Material: 316L
Thickness: 0.3-6mm
Width: 1000-2000mm
Length: according to customer's request
Surface: 2B, Hairline, No.4, BA, 8K mirror finish
SUS316L Mechanical properties in the annealed condition
| Thickness(mm) | Width(mm) | Hardness(HV) | Tensile Strength(mpa) | Yield Strength(mpa) |
|---|---|---|---|---|
| 0.05-1.5 | >200 | >520 | >205 |
Chemical composition---------------------------------------------------------------------------------
| Main Ingredient | Ni | Cr | Mn | C |
|---|---|---|---|---|
| Reference No. | 10.00/14.00 | 16.00/18.00 | ≤2.0 | ≤0.08 |
316L stainless steel common material list
| Item | XRX-SUS316L-S | XRX-SUS316L-1/4H | XRX-SUS316L-1/2H | XRX-SUS316L-3/4H | XRX-SUS316L-H |
| Hardness | 160-200 | 201-250 | 251-310 | 311-370 | 371-410 |
| Hardness Code | S | 1/4H | 1/2H | 3/4H | H |
| Thickness | Common thickness:0.1/0.12/0.15......1.5(Irregular thickness can be customized) | ||||
| Surface | 2B,2D,No.3,DF,BA,8K | ||||
316L ultra thin, super-hard material list
| Item | Hardness | Hardness Code | Thickness |
| XRX-SUS316L-H | 371-410 | H | 0.08…0.03(Ultra thin) |
Chemical composition---------------------------------------------------------------------------------
| Grade | C(Max) | Mn(Max) | P(Max) | S(Max) | Si(Max) | Cr | Ni | Mo | N(Max) | Cu/Others |
| 304 | 0.08 | 2.00 | 0.045 | 0.030 | 1.000 | 18.00-20.00 | 8.00-10.50 | - | 0.10 | - |
| 304L | 0.030 | 2.00 | 0.045 | 0.030 | 1.000 | 18.00-20.00 | 8.00-12.00 | - | 0.10 | - |
| 310S | 0.08 | 2.00 | 0.045 | 0.030 | 1.500 | 24.00-26.00 | 19.00-22.00 | - | - | - |
| 316 | 0.080 | 2.00 | 0.045 | 0.030 | 1.000 | 16.00-18.00 | 10.00-14.00 | 2.00-3.00 | - | - |
| 316L | 0.030 | 2.00 | 0.045 | 0.030 | 1.000 | 16.00-18.00 | 10.00-14.00 | 2.00-3.00 | 0.10 | - |
| 409 | 0.08 | 1.00 | 0.040 | 0.010 | 1.000 | 10.50-11.75 | 0.50 | - | - | Ti=6x(C+N) |
| 430 | 0.12 | 1.00 | 0.040 | 0.030 | 1.000 | 16.00-18.00 | 0.75 | - | - | - |
Surface Finished-------------------------------------------------------------------------------------------
| Surface Finished | Characteristics | Application |
| BA | Bright heat treatment after cold rolling. | Ktchen utenstil, Kitchenware, Architectural purpose. |
| 2B | Finished by heat treatment, pickling after cold rolling, followed by skin pass line to more brighter and smooth surface. | General application medical instruments, Tableware. |
| NO.1 | Finished by hot-rolling, annealing and pickling, characterized by white pickled surface. | Chemical industry equipment, industrial tanks. |
| 8K(Mirror) | A mirror-like reflective surface by polishing with finer abrasives over 800 mesh. | Refletor, Mirror, Interior- Exterior decoration for building. |
| Hair Line | Finished by continuous linear polishing. | Architecture industries, Escalators, Kitchenware, Vehicles. |
Packing&Shipping-----------------------------------------------------------------------------------
| Contact: Mrs. Sharon Lam Tel: 0086-755-86055888 Fax: 0086-755-82317372 Mobilephone 0086-13760280798 |
