White Conveyor Belt debossed chevron conveyor belt for food
- 300 Roll / Rolls per Month
- Tianjin/Qingdao/Ningbo
- T/T L/C D/P D/A Credit Card Other
- 10 days
Product Details
Brand Name: | TRX | Place of Origin: | China | Model Number: | SJZTRX003 |
Product Description
General Introduction:
The white conveyor belt has excellent abrasion resistance, corrosion resistance, oil resistance, non-toxic, hygienic and easy to clean, high tensile strength, non-adhesion, non-absorption, and self-lubrication.
The white rubber conveyor belt production line is specially set up independently and complies with FDA food grade certification. The main materials are ordinary cotton, nylon, polyester(EP). It can be divided into flat, chevron, pattern and sidewall. Its main ingredients are natural rubber and white carbon black.
For harmful chemical excipients, it is formulated in a small amount in strict accordance with the proportion of national standards. It is widely used in food, meat, poultry, fruit and vegetable processing, and other deep processing lines.
Features:
1, using high-strength high-quality cotton, nylon, polyester canvas as the core, the belt body is good elasticity, not easy to deform.
2, using pure natural rubber and non-pollution compounding agent to make the white or light color, no pollution, no impact on food hygiene, odor cover.
3, product formula design is reasonable, in line with health indicators, moderate color, light and durable.
We specializes in following three series: 1) Heavy-duty Conveyor Belt, including universal EP/NN and CC Belt, Chevron Belt, Oil Resistant Belt, Abrasion Resistant Belt, Heat Resistant Belt, Fire Resistant Belt, Chemical Resistant Belt, Sidewall Belt, Flat Transmission Belts, 2) Rubber Sheets, including SBR, NBR, NR, CR, EDPM, Rubber With Insertion 3) Conveyor accessories. These three series of products conform to RMA, DIN, ASTM and ISO specifications.
Its products, honored with “The most Advanced level of Products" by the Committee of Science and Technology, have been widely used in mining and quarrying, power stations, steel plants, bulk cargo terminals, cement industry, and other material handling fields. With great success in domestic market, it has been focusing on global market with several hundreds of foreign valued customers in Asia, South America, North America, Africa and Europe.
The company mission:
1.Supply one-stop outstanding service to global customers.
2.Engage in complete solutions with conveyor belting and power transmission belting.
3.Persist in technology improvement and quality control in the whole process of production and service.
The company vision:
Providing complete conveying solutions with innovation, enthusiasm and safe, eco-friendly processes to achieve operating efficiencies for our material handling customers.
White Conveyor Belt debossed chevron conveyor belt for food
The universal fabric conveyor belts are made of EP, NN or Cotton fabric and finished through the processes of calendaring, firming and vulcanizing, etc.
It is suitable to convey in normal temperature non-corrosive pointless lumps, granules or powders such as coal, coke, sand and cement in bulk or packaged.
Belts with cover grade are in accordance to International standards such as DIN 22102, RMA, AS 1332, SABS 1173/2000, IS 1891, BS 490, JIS K 6322, etc.
andards | Cover Rubber | Adhesion | ||||
TensileStrength | Elongation at break | Abrasion | Cover to Ply | Cover to Ply | Ply to Ply | |
DIN 22102 | Mpa | % | mm3 | N/mm | N/mm(>1.5mm) | N/mm |
DIN 22102-Z | 15 | 350 | 250 | 3.5 | 4.5 | 5 |
DIN 22102-W | 18 | 400 | 90 | 3.5 | 4.5 | 5 |
DIN 22102-Y | 20 | 400 | 150 | 3.5 | 4.5 | 5 |
DIN 22102-X | 25 | 450 | 120 | 3.5 | 4.5 | 5 |
Standards | Cover Rubber | Adhesion | ||||
TensileStrength | Elongation at break | Abrasion | Cover to Ply | Cover to Ply | Ply to Ply | |
RMA | Mpa | % | mm3 | N/mm(<1.6mm) | N/mm(>1.6mm) | N/mm |
RMA-I | 17 | 400 | 200 | 3 | 4.4 | 4 |
RMA-II | 14 | 400 | 250 | 3 | 4.4 | 4 |
Standards | Cover Rubber | Adhesion | ||||
TensileStrength | Elongation at break | Abrasion | Cover to Ply | Cover to Ply | Ply to Ply | |
AS 1332 | Mpa | % | mm3 | N/mm(<1.9mm) | N/mm(>1.9mm) | N/mm |
AS 1332-N17 | 17 | 400 | 200 | 4 | 4.8 | 6 |
AS 1332-M24 | 24 | 450 | 125 | 4 | 4.8 | 6 |
