SDI/HDMI HEVC H.265 Satellite Encoder YW601 RUL SRT EncoderUS$ 1000 - 1300MOQ: 1 Piece
YW601URL is one channel HD encoder for streaming media, using advanced H.265. H.264/AVC for video encoding and AAC for audio encoding. It has excellent video performance and audio reducibility under the harsh condition for low network bandwidth. In 1 Mbps video bit rate and 30kbps audio bit rate can also achieve 1080p 60/50 HD video perfect presentation. Low delay coding technology is adopted, and the 1080p 60 coding delay is lower than 160ms
To adapt to a variety of complex network audio and video application environment, YW601 URL provides a rich streaming medica protocol, such as RTMP, RTSP/RTP,HTTP,UDP,HLS etc. It can be widely used in emergency communication, network video broadcast, mobile video broadcast ,teleconference , hotel VOD, campus broadcast, hospital expert consultation and many other application fields.
Main Features
1. Embed system, very stable，low power consumption；
2. Ultralow compressed code, 1080P60 1Mbps；
3. Ultralow coding delay, less than 160ms；
4. Advanced coding technology, trebling B frame prediction，minimize bandwidth in the case of excellent image quality.
5. Well-Adapted operation，support rich streaming medica protocol, such as RTMP, RTSP/RTP,HTTP,UDP,HLS.
6. High performance cost ratio，support HDMI，HD/SD-SDI，CVBS and Analog video and audio input；
7. Support H.265/HEVC and H.264/AVC High Profile, Main Profile, Baseline coding level.；
8. Support 4 code streams in the meantime，each code stream support 4 push stream addresses or client pull stream access.
9. Support AAC audio encoding
10. Support 1080P 1080I 720P and PAL NTSC various video format input
11. Support Maximum 1080P ，and random descend to any resolution output, support vertical screen coding
12. Support audio volume adjustment function；
13. Support two way voice intercom；
14. Support publishing live streaming to Adobe FMS, Wowza，RED5 and other streaming medica servers .
15. Easy to use, embedded Web configuration, and LCD+ button configuration on the front panel of the device.
Specification
Video |
HD/SD-SDI (BNC) |
|
HDMI (HDCP Support) | ||
CVBS (BNC) | ||
Support 720x480i/p 720x576i/p 1280x720p 1920x1080i/p | ||
Audio |
HD/SD-SDI (BNC) |
|
HDMI | ||
Analog Left and right channels (XLRcannon) | ||
Analog Left and right channels (3.5mm port) | ||
Video Encoding |
Maximum processing capacity |
1920x1080P60 1280x720P60 |
Pre-treatment |
De-interlacing |
|
Coding Standard |
H.265/HEVC H.264/MPEG4-AVC |
|
Compression rate |
Minimum 1080P60 1Mbps |
|
coding delay |
Support all resolution less than 160ms 160ms |
|
resolution |
352x288 ~ 1920x1080 random adjustable |
|
Frame rate |
8Hz – 60Hz adjustable |
|
coding level Grade |
High Profile, Main Profile, Baseline random adjustable |
|
Code level |
Level 1.0 – 4.1 random adjustable |
|
Code rate |
100kbps ~ 20Mbps random adjustable |
|
Code rate control |
CBR/VBR |
|
GOP structure |
I IP IBP IBBP IBBBP |
|
GOP length |
Adjustable |
|
Video coding |
sampling precision |
24 bit |
Sampling rate |
32KHz 44.1KHz 48KHz |
|
sound track |
Stereo Mono-L Mono-R |
|
coding standard |
AAC |
|
coding rate |
30Kbps ~ 384Kbps |
|
Output |
Interface |
RJ45 10/100/1000Mbps |
output protocol |
TS Over UDP / SRT /HTTP、FLV Over HTTP |
|
RTSP/RTP | ||
RTMP | ||
HLS | ||
Two way audio |
Input |
3.5mm Micro input |
Output |
3.5mm headset output |
|
Management |
front panel |
LCD Display + 7buttons |
Internet |
WEB browser directly visit and management |
|
Electromechanical features |
Weight |
3Kg |
Size |
Standard 1U |
|
Power |
AC 110V 50/60Hz 220V 50/60Hz |
|
Power dissipation |
10W，No fans structure |
