KL Full automatic 1-20ml ketchup honey juice spicy jam liquid packing machine with CE certificate

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port NINGBO
Payment TermsT/T L/C Other

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	China	Model Number	SN-520J
After-sales Service Provided	Engineers available to service machinery overseas	Dimension(LWH)	L1500 × W1140 × H2700mm
Voltage	220V	Power	2.5KW
Function	Filling	Application	Beverage, Food, Medical
Condition	New	Automatic Grade	Automatic
Driven Type	Electric	Packaging Material	Glass, Plastic
Packaging Type	Bottles

Product Description

Usage:This machine is mainly used for ketchup/tomato sauce, chili sauce, hotpot condiment, salad cream, cooking oil, honey, yogurt, fruit juice, wine, vinegar, shampoo, hair conditioner, facial cream, medical and chemical liquid/paste quantitative packaging. This machine can automatically complete material lifting(optional)--multi-head weighter /Cup measuring(optional)--coding(optional)--bag making--filling--gas injection / exhaust (optional)--sealing--counting-- conveying finished products(optional)--sorting finished products(optional).

/automatic-liquid-sauce-packing-machine_0027

Technical parameter:

Model	SN-420J （about 100-1200g）	SN-520J （about 300g-2200g）	SN-720J （about 500g-5500g）
Packing speed	5-70 bags/min	5-60 bags/min	5-55 bags/min
Packing volume	1000ml（can be customized）	2000ml（can be customized）	4000ml（can be customized）
Making bag size	L: 60-300mm, W: 80-200mm	L: 80-400mm, W: 150-250mm	L: 80-450mm, W: 200-350mm
Film width	≤ 420mm	≤ 520mm	≤ 720mm
Thickness of film roll	0.04-0.09mm	0.04-0.09mm	0.04-0.09mm
Pulling film type	Double belt pull film	Double belt pull film	Double belt pull film
Air consumption	0.8Mpa, 0.5m³/min	0.8Mpa, 0.4m³/min	0.8Mpa, 0.4m³/min
Packing accuracy	≤ ±1%	≤ ±1%	≤ ±1%
Power	2.5 KW	2.5 KW	3.0 KW
Power supply	AC220V, 50/60Hz	AC220V, 50/60Hz	AC220V, 50/60Hz
Seal type	Pillow seal, Gusset bag, Block bottom bag	Pillow seal, Gusset bag, Block bottom bag	Pillow seal, Gusset bag, Block bottom bag
Main machine net weight	450kg	550kg	700kg
Main machine dimension	L1320 × W920 × H2100mm	L1500 × W1140 × H2700mm	L1800 × W1250 × H3100mm
