Feature:
1.High efficiency:It merely needs a few minutes to make a piece of PCB.
2.Safety :Enclosed Work Area ;Door Interlock Sensors ;Emergency Stop Button
Basic specifications:
|
X, Y cutting speed: |
0~100MM/s |
Machine Repeat Accuracy: |
± 0.01mm |
X, Y, Z Control Methods: |
Industrial IPC and PC |
X, Y, Z Drive Mode: |
AC Servo Motor |
Machine Operation and Data Storage: |
PC System |
Cutting accuracy: |
± 0.05mm |
Spindle speed: |
Max 60000rpm |
Host voltage: |
220V 1ψ 50 / 60HZ |
Air pressure supply: |
above 4.5kg/cm2 |
Power Consumption: |
1.5KVA |
Dust Collection: |
Dust Collection (Standard) or Dust Collection |
|
Dust collector voltage: |
220V (380V) 3ψ |
Upper dust collector size: |
L650*W400*H1350mm |
Dust collector size: |
L665*W635* |
Our advantage:
1.we can do the designs according to the customers' requirement
2.we can offer you the high quality & reasonable price
3.we can offer your a good after-sell service .
4.we have strong professinal design team
