Help CenterStainless Steel Ceramic Lined Ball Valve
Related Products
-
Unque Seal Dome Valve for Pneumatic Conveying System for Pneumatic Conveying SystemUS$ 600 - 3000MOQ: 2 Sets -
Electric Ceramic Lined Ball ValveUS$ 1500 - 1800MOQ: 2 Sets
-
Electric Ceramic Lined V Port Control Ball ValveUS$ 2500 - 25000MOQ: 2 Sets
-
Stainless Steel CF8 Body Zirconia Ceramic Butterfly Valve Wafer TypeUS$ 500 - 5000MOQ: 1 Piece
-
Stainless Steel CF8 Body Zirconia Ceramic Butterfly Valve Wafer Type Zirconia Ceramics SeatUS$ 500 - 5000MOQ: 1 Piece
FREE-VALVE’s stainless steel ceramic lined ball valves are designed with engineering ceramics the engineering ceramics internal parts provide excellent wear resistance, the ceramic ball valves are widely used as an open and close function as well as a throttling control tasks in corrosive medium with abrasive solids .
Features:
1.The hardness of the ceramic material can be higher than HRC80.
2.Engineering internal parts of ceramic ball valve provide superior protection from corrosive and abrasive medium.
3.Customized actuation types are installed on the ceramic ball valve, the manual lever or gear box, as well as with pneumatic and electric actuators.
4.Stainless steel valve body material makes the valve can be used in corrosive working condition ,such as seaside projects.
5.The valve has a floating ball design, the ball is floating, the ball has a defined clearance and is pressed against the downstream seat under the differential pressure to achieve sealing.
6.The valve body is in the form of 3-PCS.
Technical Specification
Thread Standards:GB,NPT
Nominal Pressure 1.0MPa,Class150
Size Range :DN10~DN 50
Connection type:Thread end,Flange end
Working Temperature ≤200℃
Operating Type:Manual operation, Pneumatic ,Electric
Sealing surface material:Engineering ceramic
Ball material:Engineer ceramic
Pressure test GB/T13927, API598
Face to Face GB/T12221, ASME B16.10
Application
FREE-VALVE’s stainless steel ceramic lined ball valves are suitable for Silicon Powder, Alumina Powder, Dry Coal Powder, Limestone Slurry, Gypsum Slurry, Plaster, , Mining Ore, Coal Powder Injection, Metallurgical dust, Thermal Power plant FGD , LiCoO2 powder equipment,Glue industry,chemical industry and food industry.
Model：FRQ11TC,FRQ311TC,FRQ611TC
Price terms:FOB,CIF,FCA,CFR
Price:100-500USD/set
Origin:China
Brand:FREE-VALVE
