SHBDM-12/SHBDM-13
Industrial Cable gland (Non-armored cable)
Materials:Brass or stainless steel,brass with nickel planted
Sealing materials:Silicon rubber,Neoprene,fluororubber
Explosion mark:Exd IIC Gb/Exe II Gb/Ex tD A21 IP66
Fireproof grade:V0(UL94)
With quick installation,safety,reliability,and other characteristics of good protection;
It is suitable for clamping and fixing various types of unarmored cables.
Environment condition:Zone1,Zone2 IIA-IIC Explosive gas atmosphere,it is widely used in petroleum, chemical, warehouse, food, pharmaceutical, military and other electrical cable fixing and sealing.
Mode |
M |
NPT |
G |
Cable range |
Thread length L |
H |
Across flats |
Across corners |
|
|
Standard
|
|||||||||
MIN |
MAX |
||||||||
SH-BDM-12-01 |
M16*1.5 |
- |
- |
3.0 |
8.0 |
15 |
21 |
19.0 |
21.2 |
SH-BDM-12-02 |
M20*1.5o |
NPT1/2 |
G1/2 |
3.0 |
8.0 |
15 |
22 |
24.0 |
27.7 |
SH-BDM-12-03 |
M20*1.5S |
NPT1/2 |
G1/2 |
6.0 |
11.0 |
15 |
23 |
24.0 |
27.7 |
SH-BDM-12-04 |
M20*1.5L |
NPT1/2,3/4 |
G1/2,3/4 |
10.0 |
14.5 |
15 |
23 |
30.0 |
34.6 |
SH-BDM-12-05 |
M25*1.5 |
NPT3/4,1 |
G3/4,1 |
13.0 |
19.5 |
15 |
24.5 |
36.0 |
41.6 |
SH-BDM-12-06 |
M32*1.5 |
NPT1,1 1/4 |
G1,1 1/4 |
19.0 |
25.5 |
15 |
27 |
46.0 |
53.1 |
SH-BDM-12-07 |
M40*1.5 |
NPT1 1/4,1 1/2 |
G1 1/4,1 1/2 |
25.0 |
31.0 |
15 |
28.5 |
55.0 |
63.5 |
SH-BDM-12-08 |
M50*1.5 |
NPT1 1/2,2 |
G1 1/2,2 |
31.5 |
37.0 |
15 |
40 |
65.0 |
75.1 |
SH-BDM-12-09 |
M63*1.5 |
NPT2,2 1/2 |
G2,2 1/2 |
42.5 |
55.0 |
15 |
37 |
80.0 |
92.4 |
SH-BDM-12-10 |
M75*1.5 |
NPT2 1/2,3 |
G2 1/2,3 |
54.5 |
64.0 |
15 |
40 |
95.0 |
109.6 |
Mode |
M |
NPT |
G |
Cable range |
Thread length L |
H |
Across flats |
Across corners |
|
|
Standard
|
|||||||||
MIN |
MAX |
||||||||
SH-BDM-13-01 |
M16*1.5 |
- |
- |
3.0 |
8.0 |
15 |
40 |
19.0 |
21.2 |
SH-BDM-13-02 |
M20*1.5o |
NPT1/2 |
G1/2 |
3.0 |
8.0 |
15 |
40 |
24.0 |
27.7 |
SH-BDM-13-03 |
M20*1.5S |
NPT1/2 |
G1/2 |
6.0 |
11.0 |
15 |
40 |
24.0 |
27.7 |
SH-BDM-13-04 |
M20*1.5L |
NPT1/2,3/4 |
G1/2,3/4 |
10.0 |
14.5 |
15 |
40.5 |
30.0 |
34.6 |
SH-BDM-13-05 |
M25*1.5 |
NPT3/4,1 |
G3/4,1 |
13.0 |
19.5 |
15 |
44.3 |
36.0 |
41.6 |
SH-BDM-13-06 |
M32*1.5 |
NPT1,1 1/4 |
G1,1 1/4 |
19.0 |
25.5 |
15 |
48 |
46.0 |
53.1 |
SH-BDM-13-07 |
M40*1.5 |
NPT1 1/4,1 1/2 |
G1 1/4,1 1/2 |
25.0 |
31.0 |
15 |
49 |
55.0 |
63.5 |
SH-BDM-13-08 |
M50*1.5 |
NPT1 1/2,2 |
G1 1/2,2 |
31.5 |
37.0 |
15 |
63 |
65.0 |
75.1 |
SH-BDM-13-09 |
M63*1.5 |
NPT2,2 1/2 |
G2,2 1/2 |
42.5 |
55.0 |
15 |
63.2 |
80.0 |
92.4 |
SH-BDM-13-10 |
M75*1.5 |
NPT2 1/2,3 |
G2 1/2,3 |
54.5 |
64.0 |
15 |
70 |
95.0 |
109.6 |
