Help CenterMTO-170 Slewing Bearing
US$ 10 - 300
MOQ: 2 Pieces
Key Specifications
Get Latest Price
Brand Name:
RIGBRS
Place of Origin:
China
Model Number:
MTO-170
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
45 days
Related Products
-
RKS.210941 Slewing Bearing ChinaUS$ 500 - 1500MOQ: 2 Sets -
RKS.23 1091 Slewing Bearing Light Series Slewing RingUS$ 100 - 500MOQ: 2 Sets
-
33-0641-01 Slewing Ring Bearing 572x716x56mmUS$ 10 - 500MOQ: 2 Pieces
-
MTO-122 Slewing BearingUS$ 10 - 100MOQ: 5 Pieces
-
VI140326-V Slewing Ring BearingUS$ 10 - 500MOQ: 5 Pieces
Brand Name
RIGBRS
Place of Origin
China
Model Number
MTO-170
Feature
Cross Roller
Seals Type
NBR, sealed both sides.
Outside Diameter
310,
Bore Size
170,
Gear Options
Nongeared
MTO-170 Bearing specifications
Inner ring: 170mm
Outer ring: 310mm
Height: 46mm
Mounting dimensions Li: 200mm
Mounting dimensions Lo: 280mm
Weight: 15kg
Structure: four-point contact ball slewing bearing without gear
Materials: 42CrMo/50Mn/customized
Clearance: 0.07~0.17mm
Lubrication Type: Grease lubrication/Lubrication hole: Yes
Load direction: axial, radial, and tilting moment.
Four-point contact ball slewing bearing with an integrated inner and outer ring.
Grinding the finished bearing surface and raceway, provide lower friction and higher rotation accuracy.
-
With mounting holes on the inner and outer rings, easy to install and remove bearings.
MTO slewing bearing models (unit: mm)
| Model | di | Do | H | Li | ni - Bi | Lo | no - Bo | Weight(kg) |
| MTO-050 | 50 | 110 | 20 | 63 | 8-φ6.6 | 97 | 8-φ6.6 | 0.9 |
| MTO-050T | 50 | 110 | 20 | 63 | 8-M6 | 97 | 8-M6 | 0.9 |
| MTO-065 | 65 | 135 | 22 | 80 | 8-φ9 | 120 | 8-φ9 | 1.8 |
| MTO-065T | 65 | 135 | 22 | 80 | 8-M8 | 120 | 8-M8 | 1.8 |
| MTO-122 | 122 | 226 | 34 | 140 | 12-φ9 | 208 | 12-φ9 | 6 |
| MTO-122T | 122 | 226 | 34 | 140 | 12-M8 | 208 | 12-M8 | 6 |
| MTO-143 | 143 | 249 | 34 | 165 | 12-φ11 | 227 | 12-φ11 | 6.8 |
| MTO-143T | 143 | 249 | 34 | 165 | 12-M10 | 227 | 12-M10 | 6.8 |
| MTO-145 | 145 | 300 | 50 | 175 | 16-φ14.3 | 270 | 16-φ14.3 | 16.8 |
| MTO-145T | 145 | 300 | 50 | 175 | 16-φ15.875 | 270 | 16-φ15.875 | 16.8 |
| MTO-145X | 145 | 312 | 50 | 175 | 16-φ15.1 | 270 | 16-φ15.1 | 18.6 |
| MTO-170 | 170 | 310 | 46 | 200 | 12-φ13 | 280 | 12-φ13 | 15 |
| MTO-170T | 170 | 310 | 46 | 200 | 12-M12 | 280 | 12-M12 | 15 |
| MTO-210 | 210 | 365 | 40 | 240 | 20-φ14.3 | 335 | 16-φ14.3 | 17.2 |
| MTO-210T | 210 | 365 | 40 | 240 | 20-φ15.875 | 335 | 16-φ15.875 | 17.2 |
| MTO-210X | 210 | 373 | 50 | 240 | 20-φ15.1 | 335 | 16-φ15.1 | 21.8 |
| MTO-265 | 265 | 420 | 50 | 295 | 24-φ14.3 | 390 | 18-φ14.3 | 24.5 |
| MTO-265T | 265 | 420 | 50 | 295 | 24-φ15.875 | 390 | 18-φ15.875 | 24.5 |
| MTO-265X | 265 | 434 | 50 | 295 | 24-φ15.1 | 390 | 18-φ15.1 | 27.7 |
