RAU1005 Micro Crossed Roller Bearings 10x21x5mm
US$ 10 - 500
MOQ: 5 Sets
Key Specifications
Get Latest Price
Brand Name:
RIGBRS
Place of Origin:
China
Model Number:
RAU1005
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
45 days
Related Products
Brand Name
RIGBRS
Place of Origin
China
Model Number
RAU1005
Feature
Cross Roller
Seals Type
sealed both sides
Outside Diameter
21, 111
Bore Size
10, 100
Gear Options
Nongeared
RAU1005 micro crossed roller bearings specifications
size: 10x21x5mm
structure: Ultra-thin section micro crossed roller bearings with an integrated inner ring and outer ring.
sealing: sealed both sides
clearance: C0
precision: radial/axial runout below 13μm
RAU1005 crossed roller bearings are specially designed for limited space. The width of the RAU micro cross roller ring is only 5mm, so the processing is more difficult than common crossed roller bearings.
| Model No. | d (mm) | D (mm) | B (mm) | Cr (kN) | Cor (kN) | Mass(kg) |
| RAU1005 | 10 | 21 | 5 | 1.12 | 0.809 | 0.009 |
| RAU1505 | 15 | 26 | 5 | 1.32 | 1.1 | 0.012 |
| RAU2005 | 20 | 31 | 5 | 1.49 | 1.4 | 0.015 |
| RAU3005 | 30 | 41 | 5 | 1.89 | 2.14 | 0.021 |
| RAU4005 | 40 | 51 | 5 | 2.14 | 2.74 | 0.027 |
| RAU5005 | 50 | 61 | 5 | 2.43 | 3.49 | 0.032 |
| RAU6005 | 60 | 71 | 5 | 2.63 | 4.09 | 0.038 |
| RAU7005 | 70 | 81 | 5 | 2.81 | 4.68 | 0.044 |
| RAU8005 | 80 | 91 | 5 | 3.05 | 5.43 | 0.05 |
| RAU9005 | 90 | 101 | 5 | 3.19 | 6.03 | 0.056 |
| RAU10005 | 100 | 111 | 5 | 3.37 | 6.03 | 0.061 |
