LED Single/Double Output Adjustable Power Supply
- China port
- T/T Credit Card
You May Like
Product Details
| Brand Name | BOCHI | Place of Origin | Chongqing, China | |
| Model Number | BOCHIMEE4 | |||
| Output Current | 0-A can be adjusted | |||
| Output Frequency | 50/60Hz | Output Voltage | 0-V can be adjusted | |
| Input Voltage | 220V |
carton
Product Description
LED Single/Double Output Adjustable Power Supply
Application:
Applied to teaching experiments, research, testing and aging of electronic production lines, communications equipment maintenance, and other areas that require DC power supply.
Products characteristic:
1.LED digital panel displays the output current and voltage values
2.Equipped with four rotating regulator, coarse and fine fraction, the operation more convenient and more accurate
3.With a steady flow function,CV/CC can be automatically converted
4.Output voltage and current from 0 to nominal value continuously adjustable
5.OVP / OCP multiple protection, safe to operate and longer lifespan
6.Low ripple, low noise, beautiful apperance , full-featured, excellent cost-effective
7.Continuous long-term work at full load
Technical Parameter:
Input volateg | AC220V/110V±10% | |
Input frequency | 50Hz/60Hz | |
Output voltage | 0-V can be adjusted | |
Output current | 0-A can be adjusted | |
Stable voltage | Voltage stability | no more than 0.01%+3mV |
Load stability | no more than 0.01%+5mV | |
Recovery Time | no more than 100us | |
Ripple noise | no more than 1mVrms | |
Temperature Coefficient | no more than 300PPM/℃ | |
Stable current | Current stability | no more than 0.2%+3mA |
Load stability | no more than 0.2%+3mA | |
Ripple noise | no more than 3mArms | |
Protection | Current automatic limit protection, short circuit protection, automatic protection | |
Working condition | Temperature | -10-40℃ |
Relative humidity | no more than 80%RH | |
Storing condition | Temperature | -10-80℃ |
Relative humidity | no more than 80%RH | |
Single Output Model:
Output current | 0~15V | 0~30V | 0~60V | |||
Type /Power | Type /Power | Type /Power | ||||
0~2A | WYJ-1502D | 30W | WYJ-3002D | 60W | WYJ-6002D | 120W |
0~3A | WYJ-1503D | 45W | WYJ-3003D | 90W | WYJ-6003D | 180W |
0~5A | WYJ-1505D | 75W | WYJ-3005D | 150W | WYJ-6005D | 300W |
0~10A | WYJ-1510D | 150W | WYJ-3010D | 300W | WYJ-6010D | 600W |
0~15A | WYJ-1515D | 300W | WYJ-3015D | 600W | WYJ-6015D | 1200W |
0~20A | WYJ-1520D | 450W | WYJ-3020D | 900W | WYJ-6020D | 1800W |
Double Output Model:
Output current | 0~15×2V | 0~30×2V | 0~60×2V | |||
Type /Power | Type /Power | Type /Power | ||||
0~2A×2 | WYJ-1502B2 | 60W | WYJ-3002B2 | 120W | WYJ-6002B2 | 240W |
0~3A×2 | WYJ-1503B2 | 90W | WYJ-3003B2 | 180W | WYJ-6003B2 | 360W |
0~5A×2 | WYJ-1505B2 | 150W | WYJ-3005B2 | 300W | WYJ-6005B2 | 600W |
0~10A×2 | WYJ-1510B2 | 300W | WYJ-3010B2 | 600W | WYJ-6010B2 | 1200W |
0~15A×2 | WYJ-1515B2 | 600W | WYJ-3015B2 | 1200W | WYJ-6015B2 | 2400W |
0~20A×2 | WYJ-1520B2 | 900W | WYJ-3020B2 | 1900W | WYJ-6020B2 | 3600W |
